New Hose Iso 9352 Abrasion Tester - China

New Hose ISO 9352 Abrasion Tester Introduction of Hose Wear Tester:

It is mainly used to measure the wear resistance of hydraulic hoses and other similar hoses with fabric or steel wire reinforcement, and with a smooth and flat surface.

This equipment meets the requirements of GB/T2721-2007/ISO6945: 199 1 - It is specially designed to measure the outer layers of rubber hoses and other similar types of hoses with a fabric or steel wire reinforcement layer and an outer covering layer with a smooth and flat surface.

Abrasion resistant instruments.

At the same time, the wear resistance of other pipes and plates can also be measured.

It is an indispensable test instrument for rubber hose manufacturers, scientific research units and quality inspection units.

Hose abrasion testing machine conforms to the standard:

"GB/T12721-2007"

"ISO6945: 1991"

"Determination of Wear Resistance of Rubber Hose/Overcoat" Main technical parameters of hose abrasion testing machine:

Dimensions: 900X520X680 (length X width X height)

Weight: about 150 kg;

Power supply: AC 220V, 5A

Number of experimental groups: three groups or one group

Specimen specifications: inner diameter 5, 8, 10, 13, 16, 19, 22, 25, 32, 38, 45, 51 mm, length 150 mm

Applied static pressure: 50N, 100N

Cycle times setting: up to 999999 times

Hose abrasion tester packing list:

1 - A set of host (with clamping tooling)

2 - Counterweight: 4 pieces of 10N counterweight blocks, 2 pieces of 5N counterweight blocks

3 - One piece of mold

4 - Test mandrel: Φ19, Φ22, Φ25 three pieces.

ps: (WLJCDM809)
