Rigid Foam Horizontal Vertical Flame Tester Doha - China

ZY6017B-VB rigid foam Horizontal Vertical Flame Tester is suitable for evaluating the vertical combustion performance of rigid foam under laboratory conditions.

Features: It has the characteristics of simple operation, reasonable structure and accurate testing.

Fourth, product parameters: 1 - Box: 0.3m3 (L700mm*W490mm*H870mm); 2 - Specifications of the crater: inner diameter (9.5±0.5)mm, barrel length 115mm, 15° to the vertical direction.

3 - Flame height: blue flame with a height of (25~35)mm; 4 - Gas: propane or natural gas with a purity of more than 95%; 5 - The temperature of the inner flame measured by a K-type thermocouple is (960±25)℃; 6 - Instrument composition: fume hood, chimney, sample holder and control part; 7 - Chimney: 64mm long, 57mm wide, 305mm high, made of stainless steel, with 0.025mm thick aluminum foil inside; 8 - Sample holder: length 191mm, width 13mm made of stainless steel, with hooks on the back; 9 - Gas flow: 0.1~1L/min adjustable; 10 - Timer: 0~99.99s can be set arbitrarily, accuracy ≤0.1s; 11 - Test scale: the minimum scale is 1.0mm; 12 - Standard sample specifications: length (254±1)mm, width and thickness are both (19±1)mm; 13 - Dimensions: L710mm*W500mm*H1440mm; 14 - Working power supply: AC220V, 50HZ; total power is 500W.

ps: (WLJCDM809) Tag:

horizontal flammability tester, horizontal flame test, vertical flame test, horizontal vertical flammability tester, horizontal & vertical flammability tester, horizontal flame chamber tester, ul94 vertical and horizontal flammability tester, ul94 horizontal and vertical flame testing machine, flammability tester, flame test, horizontal burning tester, vertical flammability tester, horizontal burning behavior tester, horizontal burning rate tester, flame test machine
