Horizontal Gb8410 Flammability Tester - China

Horizontal combustion tester/gb8410 combustion tester The horizontal combustion tester/gb8410 combustion tester adopts the measurement method of the combustion performance in the horizontal direction, which is suitable for the determination of the relative combustion rate and flame retardancy of various textile fabrics, clothing, tents, etc., especially the interior decoration fabrics of automobiles.

Scope of application: Seat Cushions, Seat Backs, Seat Covers, Seat Belts, Headrests, Armrests, Convertible Roofs, All Decorative Liners, Instrument Panels, Glove Boxes, Interior Cargo Shelf Plates, or Rear Sills, Curtains, Floor coverings etc.

Standards compliant: GB 8410, ISO 3795, FMVSS 302, DIN 75200, SAE J369, ASTM D5132, JIS D 1201, AU 169 technical parameter: 1 - Flame application time: 0-999.9s±0.1s adjustable; 2 - Delay time: 0-99h59m59.99s±0.1s, manual start/pause; 3 - Installation of combustion box: the bottom of the combustion box is 10mm away from the bottom plate of the equipment; 4 - Test wind speed: the vertical air velocity of each 100mm before and after the combustion box is between 0.10m/s and 0.30m/s, and an anemometer is added to the right side of the equipment to monitor the outlet; 5 - U-shaped bracket: made of two U-shaped stainless steel plates, there are 2 pin holes behind the upper bracket, and 2 pins corresponding to the lower bracket, and are arranged with heat-resistant metal supports with a wire diameter of 0.25mm and a spacing of 25mm Wire; 6 - Gas lamp: the inner diameter is 9.5mm, and the center of the nozzle mouth is 19mm below the center of the free end of the sample and can be automatically ignited; 7 - Gas: use liquefied gas, or other combustible gas (such as natural gas, city gas) with a combustion calorific value of 35MJ/m3~38MJ/m3; 8 - Power supply: 220VAC-15%～220VAC+10% 500W (single-phase three-wire system).

PS: (WLJCDM809-W) Qinsun Instruments Co., Ltd
