Parameter Sharing Of Laboratory Warm Up Dummy - China

Parameter sharing of laboratory warm-up dummy Product parameters:

The body shape and size conform to the physiological and anatomical characteristics of the human body;

1 - #Model size: The model is the average height of Asian males.

2 - #Standard measurement area: 22 independent control thermal energy areas

3 - Section area: head-1391cm2, front chest-1880cm2, back-1780cm2, abdomen buttocks-1808cm2, thigh-1696cm2×2, calf-1203cm2, feet-572cm2×2, arms-1234cm2×2

4 - Connection: Seams at shoulder, hip, knee, elbow and ankle joints

5 - Weight about 30 kg

6 - #Standard clothing size M;

7 - The central temperature variation range: 37±0.1℃.

8 - The whole body heating wire and wired temperature and humidity sensors (including 18 temperature sensors and 18 humidity sensors) can accurately control and measure the skin temperature, the temperature sensor accuracy is ±0.1℃, and the humidity sensor accuracy is: ±3%

9 - Under normal circumstances, the maximum heating power is 1200W/㎡ (dry and wet state);

10 - It can also be used in wet skin conditions;

11 - Use environment requirements: temperature -50 to 150 ℃, humidity 0 to 100%;

Temperature system:

1 - Range: 0-55℃

2 - #Accuracy: ±0.1℃

3 - System default: 37℃

4 - The maximum temperature difference between adjacent areas: 3℃

5 - Standard temperature measurement area: 22 independent control thermal energy areas

6 - Heating method: hot plate type (uniform and stable) or extremely stable heating wire

7 - Measurement method: Wired sensor measurement, 0.5mm below the skin surface, protected by fine copper epoxy with high conductivity.

8 - Control method: independent electronic control inside the human body to ensure accurate maintenance;

Sweat system:

1 - Perspiration method: detachable fabric skin layer

2 - #humidity: control accuracy ±3%, resolution 0.1%

3 - Perspiration rate: custom, adjustable

4 - Sweat preheating: built-in

5 - Sweat volume: 0-600g/m2?h

surveillance system:

1 - Including 1 computer, software control system, monitoring system

2 - The computer control analysis software can control and monitor the normal operation of the above components in real time, collect data and further calculate and display the test results in real time (clothing thermal resistance value, clothing moisture resistance value, clothing moisture permeability, clothing clo value, etc.

), providing data Analysis, data storage and printout functions; analysis software provides results such as thermal resistance value, moisture resistance value, Crow value, moisture permeability and other results; the testable indicators of the entire system are: dynamic (static) thermal resistance value and moisture resistance value, and realize dynamic storage and reproduction of process parameters such as temperature, humidity, power, water circulation, and sweat volume.

PS: (WLJCDM809-W)
