Polyester Materials Dust Filter Bag Lower Fiber Release Prolonging Service Life - China

Polyester Materials Dust Filter Bag Lower Fiber Release Prolonging Service Life Quick Detail:

Material : PP or PE, polyester, polypropylene

Micron rating : 0.5um ~800um

Good anti abrasion

High temperature grade

Anti acid, anti alkali, chemical resistance

High porosity, good air permeability

Laminated compound, grads counterchange Description:

Low temperature resistance ( 88-110 )

Excellent resistant to hydrolysis, acids and alkalies.

Smooth surface, more defined pore size and good air permeability

Lower fiber release, Lower density, High mechanical characteristics Specifications:

#1(7"x16") 180*410mm

#2(7" x 32") 180*810mm

#3(4"x 8 1/4") 102*210mm

#4(4"x 14") 102*356mm - - - -

Material | PE, PP, NMO, PTFE | Cuff | PP Lock, Stainless steel | Relative filtration pore size | 0.5, 1, 5, 10, 25, 50, 100, 200 m | Type | various specifications | Airtight method: | Hot Melt, reverse sewing | Effective filtration area | various specifications | Others | special requirement of diameter and collar extension can be customized | - - - - - - - -

Model No.

| Material | Weight | Thickness | Breaking strength | Using temperature | | | g/m2 | mm | vertically | horizontally | | polyester needle felt | polyester fibre | 400-650 | 1.7-2.05 | 900-1140 | 1100-2000 | 130 | polypropylene needle felt | polypropylene fibre | 400-650 | 1.8-2.6 | 950-1500 | 900-1400 | 130 | anti-static needle felt | polyester fibre

electric fibre | 400-600 | 1.6-2.4 | 1000-1400 | 800-1200 | 130 | water and oil replelient needle felt | polyester fibre

teflon coating | 400-600 | 1.4-1.9 | 900-1140 | 1100-2000 | 130 | FMS needle felt | high temperature resisting fibre | 800 | 1.8 | 1600 | 1400 | 260 | metamax needle felt | metamax fibre | 500 | 2.3 | 1000 | 900 | 204 | PPS needle felt | poly-p-propylence | 500-550 | 2.0 | 800 | 1200 | 170 | PTFE coated needle felt | polyester fibre or metamax needle felt

PTFE coating | 400-650 | 1.4-2.3 | | | 260 | P84 | P84 fiber | 500 | | | | 260 | fiberglass | glass fiber | 900 | | | | 240 | - - - -

Advantages

1 - dust collector filter bag are carefully fabricated and sized to ensure ease of installation and

change-out.

2 - dust collector filter bags are designed to be mounted and gasketed firmly into place with a snap band, corded cuff, or clamp to ensure dust tight seal.

3 - Various coatings and finishes can be applied to either side of the dust collector bag to enhance cleaning and efficiencies, as well as prolonging service life.

4 - Groundwire, anti-collapse rings and other options can be easily incorporated into bag construction.

Filter bag is theheartof a dust collector, and it plays a very important part in dust collection.

Filter bag performance effects directly on the dust collecting efficiency.

Polyester needle felt is a widely used filter bag material which has great intensity and elastic

recovery, steady fiber dimension, good anti-wear property, large porosity, good air permeability, long serving life, high dust collecting efficiency.

It shows good mechanical properties and acid and alkali resistance

at normal temperature.

Polyester needle felt is a good option with good properties and appropriate price.

Characters of dust such as temperature, proportion, size, adhesion, concentration, humidity, explosibility and filtration velocity should be considered before choosing filter bag to achieve an optimum efficiency.

Notices:

1 - Materials avaliable: polyester, polypropylene

2 - construction: welded or sewn

3 - collar type: steel ring or plastic ring

4 - finishing treatment: singed, calendared, heat set

5 - Size available: standard and custom size.

Application fields:

1) The fume and smoke treatment and particle removing system in metallurgy plant, alloy plant, steel works, moulding factories, fire-retardant factories and power stations 2) Fume filtration, tiny particle recycle and division of liquid and solid in aluminum electro analysis, tin, zinc, cooper and other rare metals 3) Smoke filtration in garbage burning, coal-feed boiler and liquidized laid boilers 4) Division of liquid, solid and tiny particle recycle in chemicals, coke, carbon, dyestuff, pharmacy and plastics 5) Asphalt concrete mixture, cements, ceramics, building materials, lime and plaster 6) Dust treatment, purification and collection in electronics, mining, foodstuff processing, flour and timber processing.

As one of the leading suppliers of air filtration customed polyester dust filter bag filter fabric for dust collector in China, Daitto Group Company now has quite a few products in stock in its factory.

Also dealing with customized service, we warmly welcome you to buy or wholesale discount and cheap products at low price with us.

And free sample is also available if you need.
