Tsa004 Japanese Standard Electric Rubbing Color Fastness Tester - China

TSA004 electric rubbing color fastness tester is mainly used for evaluating and judging the color fastness to rubbing of dyed fiber products.

Use dry or moist white cotton cloth to tie the surface of the friction hammer of the machine, rub the colored test piece with a certain load and number of times, and compare the gray scale to evaluate the dyeing rubbing fastness level.

It can also be used as a friction test for organic solvents.

Standard: JIS-L0801, 0823, 0849, 1006, 1084, K6328, P8136 Number of test samples: 6 groups Movement curve: arc, (curve radius 200mm) Friction speed: 30cpm Friction hammer load: 2N Reciprocating distance: 120㎜ Friction hammer size: 2cm × 2cm (R) 45 × 50mm White cotton cloth pollution area: 1c㎡ Friction shape: curved surface (radius of curved surface 45mm) Counter: LCD liquid crystal display, 0～999, 999 Volume: 550×550×350mm Power supply: 1∮ AC220V, 3A The standard configuration: TSA004A Standard Abrasive Cloth (1000pcs/box) 1 - Compatible standard: JIS L 0849 GB 2 - Instrument introduction: This machine is a testing machine based on the rubbing tester type 2 (gakuchan shape) specified in the color fastness test of textiles in the Japanese Industrial Standard and the test method for color fastness to rubbing (JIS L 0849).

It is mainly used to evaluate and judge the color fastness to rubbing of dyed fiber products.

Through the exchange of various accessories sold separately, it can be applied to the [hair flocking strength test] of flocked fabrics, the [friction decolorization test] of artificial leather, and the friction and abrasion resistance test of cardboard, printing, ink, paint, etc.

A friction tester that can be applied to various materials.

3 - Features of the instrument: *Motor and other devices are stored in the lower part of the testing machine, with high safety *The use of drive bearings does not require oil-filled bearings *Applicable to various tests by exchanging various accessories for sale SOURCE: Qinsun Instruments Co., Ltd
