China 14600kg Hydraulic Crawler Excavator Xe150d With Competitive Prices - China

price: 71000.00 Dollar US$

XE150D Crawler Excavator 1 - The overall layout and the axle load distribution are more reasonable to achieve better traveling stability and the maximum traveling speed is up to 40km/h to realize faster site transfer speed.

2 - The domestic leading hydraulic system distribution technology features high energy-saving and efficiency.

3 - The highest breakout force on the loading end is leading the industry by 15%~20% compared with like models.

4 - The advanced structure and hinge points on the digging end and the industry's largest rotating angle of the bucket ensure strong soil holding capacity.

Specification Item

Parameters

Engine

Model

QSF3.8

Equipped

Electronic fuel injection

Four strokes

Water cooling

Turbo-charging

Air to air intercooler

No.

of cylinders

4

Output power

93/2200 kW/rpm

Torque/speed

500/1300 N.

m/rpm

Displacement

3.76 L

Operation Weight

14600 kg

Bucket Capacity

0.32-0.71 m ³

Main performance

Travel speed(H/L)

5.3/3.2 km/h

Rotating speed

11.7 r/min

Gradeability

35°

Ground pressure

37 kPa

Bucket digging force

106.9 kN

Arm digging force

73.4 kN

Maximum traction

184 kN

Hydraulic system

Main pump

K7V63DTP

Rated flow of main pump

2×123.5 L/min

Pressure of prime valve

34.3/37.0 Mpa

Pressure of pilot system

3.9 Mpa

Oil capacity

Fuel tank capacity

260 L

Hydraulic tank capacity

105 L

Engine oil capacity

11 L

Appearance size

Overall dimensions(L*W*H)

7795×2590×2900 mm

Width of platform

2490 mm

Width of crawler

600 mm

Crawler gauge

1990 mm

Clearance under counterweight

948 mm

Min.

ground clearance

477 mm

Min.

tail swing radius

2325 mm

Working scope

Max.

digging height

8649 mm

Max.

dumping height

6185 mm

Max.

digging depth

5535 mm

Excavation depth of 8 feet level

5324 mm

Max.

vertical wall digging depth

4697 mm

Max.

digging reach

8304 mm

Min.

swing radius

2445 mm

Standard

Boom length

4600 mm

Arm length

2520 mm

Bucket Capacity

0.61 m ³

Optional

Arm length

2100/3010 mm

Bucket Capacity

0.32/0.4/0.71/0.52


Company Contact:


  • Phone: +8615242642683

  • Address: Super Ocean Finance Center 28F,No.2067 West Yanan Road Shanghai,, shanghai , shanghai , China

  • Email: Email


Published date: May 23, 2019

  • Business Description: "We are a professional exporter in Shanghai, China for 8 years, specializing in construction machinery & Industrial Equipment.

    You will get the best service and product made by Chinese famous brand with most competitive price!

    Feel free to contact me if you have any question.

    I would like you to get fitting products.

    "
