Hammer Grab For Piles Large Size 1500mm 3000mm Diffrent Soil Conditions Sand - China

HAMMER GRAB FOR PILES small size 1000mm-2000mm for diffrent soil conditions (sand, gravel, clay, sandstone and granite small to medium size hammer grabs is designed and manufactured to excavate circular piles from 1000 to 2000 mm diameter in a heavy wide range of soil conditions (sand, gravel, clay, sandstone and granite) with a cohesive value up to 15.000 kg/m2 supported and operated by a single line or double line

The hammer grab is the most important tool in pile construction and it determines the drilling progress.

Double rope hammer grab with high closing force especially suitable for vibration free boring in semi hard soil conditions Hydraulic Spherical Grab The hydraulic turning device enables the grab to be turned ±100° to ensure a calibration of the borehole.

The high deadweight in conjuntion with the high closing force ensures a high effiniency.

The hydraulic spherical grab is used on jobs, where drilling has to be carried out free of vibrations an/or where partially cased or uncased drilled shafts are to be produced single rope hammer grab, double rope hammer grab Model CASING DIAMETER MM

DOWN DIAMTER MM

UP DIAMETER

CAPACITY

L

WEIGHT

KG

CZD/C1300

1500/1420

1300

1200

400

8000

CZD/C1400

1600/1520

1400

1300

450

9400

CZD/C1500

1700/1620

1500

1400

700

10600

CZD/C1600

1800/1720

1600

1500

790

11530

CZD/C1700

1900/1720

1700

1600

920

12700

CZD/C1800

2000/1920

1800

1700

1000

14000

CZD/C1900

2100/2020

1900

1800

1200

14820

CZD/C2000

2200/2120

2000

1900

1450

15400

CZD/C2100

2300/2220

2100

2000

1580

16650

CZD/C2200

2400/2320

2200

2100

1750

17600

CZD/C2300

2500/2420

2300

2200

1900

19000

CZD/C2400

2600/2520

2300

2300

2150

20500

CZD/C3000

3200/3020

3000

2900

3900

24150
