Highway Guardrail Forming Machine - China

price: 50000.00 Dollar US$

Highway Guardrail Forming Machine

Products Photos Catalog Highway Guardrail Photos Catalog

1 - Outline of machine: 18000mm(L)*3000mm *1300mm

2 - Total weight of machine: about 20T

3 - Main motor power: 30KW

4 - Reducer: PM750 reducer, speed ratio 1: 31.75

5 - Structure frame: 400MM H steel welded

6 - Base of gear box: adopt steel plate welded, and milling.

7 - Gear box and main shaft adopt universal coupling connection

8 - Mid-plate thickness: 20mm.

9 - Main shaft: 45# steel, through quenching and tempering.

diameter of shaft: 90mm

10 - Bearing: 6215

11 - Roller: bearing steel, through coarse machining by common lathe, finish machining by CNC lather, quenching, surface polishing and plate hard chrome.

12 - Number of forming stand: 26 groups

13 - Thickness of feeding sheet: 2-4mm

14 - forming speed: about 3-5meter/min

15 - Punching method: hydraulic Pre-punching.

Punching mould adopt CR12steel, through coarse grinding, heat treatment, accurate grinding and line cutting formed


Company Contact:


  • Phone: 0086-13513038763

  • Address: Development Zone,BOTOU,China, BOTOU , HEBEI , China

  • Email: Email


Published date: May 22, 2020

  • Business Description: steel for construction .

    such as guard rail roll forming machinery series , cable tray roll forming machinery series , C&Z purline roll forming machinery series , wall and roof panel roll forming machinery series , and so on .
