Step Glazed Tile Forming Machine 840 - China
price: 7000.00 Dollar US$
1 suitable material: PPGI, GI
2 Width of the plate：1000mm
3 Rows of rollers：11 stations
4 Size: 5.8M(L)*1.3M(W)*1.2m (H)
5 Main motor power: : 3KW 4# reducer 6 Thickness of raw material: 0.3-0.8mm
7 Productivity : 8~12m/min
8 diameter of shaft: ￠70mm
9 Weight: About 2T
10 Voltage: 380V 50Hz 3phases
11 Middle Plate Thickness 14MM
12 - Press Mould: Use press mould for step
Company Contact:
- Posted By: Botou Roll Forming Machine Co.,ltd
- Phone: 0086-13513038763
- Address: Development Zone,BOTOU,China, BOTOU , HEBEI , China
- Email:
Published date: May 22, 2020
- Business Description: steel for construction .
such as guard rail roll forming machinery series , cable tray roll forming machinery series , C&Z purline roll forming machinery series , wall and roof panel roll forming machinery series , and so on .
