1x2 Reinforcing Woven Welded Wire Mesh Panels Sheets For Concrete - China

1x2 Reinforcing Woven Welded Wire Mesh Panels Sheets For Concrete Product Introduction Features of reinforcing mesh The unique deformed wire pattern (curry pattern) offers superior bonding, improved stress distribution and crack-width control Ferro-Fabric is available in a wide range of diameters and apertures.

The products can be bent to shape as required Manufactured from hard drawn wire (smooth) and cold rolled wire (deformed) All intersections are resistant-welded thereby not reducing the tensile strength of the wires Mesh has an average shear strength equal to 80% of the wire strength The wire used has physical properties which are rigidly controlled to produce mesh with maximum weld strength combined with ductility The steel specifications allow for cold rolled wire with a minimum ultimate tensile strength of 510Mpa and a high resistance to fatigue Mesh is available in black (pre-galvanised) and galvanised sheets or rolls Also available on request: plastic coated and hot dipped (galvanised) mesh Quality Control Reinforcing mesh is produced to highest quality standards and complies to ISO 9002 - Thorough testing of wire strength, welds and aperture sizes is continuously performed at all stages of the manufacturing process.

Final inspections ensure that highest standards are maintained.

Standard Sizes Reinforcing mesh is available in rolls (60m x 2, 4m) and sheets (6m x 2, 4m), manufactured according to standard sizes.

Wire diameters vary from 3, 55mm to 12mm.

Mesh aperture can be as small as 100mm x 100mm.

Special Mesh Specialized machinery is used to produce weld mesh with non-standard aperture sizes.

The spacing of wires in either direction is variable between 25mm and 150mm.

Customized mesh is available on request according to specifications provided.

Reinforcing Mesh Data Sheet Standard sizes of welded mesh fabric Specifications: Sheets: 6m x 2, 4m or Rolls: 60m x 2, 4m Based on SABS 1024/2006 specifications for welded steel fabric for concrete reinforcement - - - - Opening | Wire diameter | Width | 1/4" x 1/4" | 0.5mm-0.7mm | 300mm-1828mm | 3/4" x 3/4" | 0.7mm-2.0mm | 300mm-1828mm | 3/8" x 3/8" | 0.7mm-1.1mm | 300mm-1828mm | 5/8" x 5/8" | 0.8mm-1.2mm | 300mm-1828mm | 1/2" x 1/2" | 0.45mm-1.6 mm | 300mm-1828mm | 1" x 1" | 0.7mm-3.0mm | 300mm-2000mm | 1" x 1/2" | 0.8mm-1.6mm | 300mm-1828mm | 1-1/2" x 1-1/2" | 0.7mm-3.5mm | 300mm-1828mm | 1" x 2" | 1.6mm-2.1mm | 300mm-1828mm | 2" x 2" | 0.7mm-4.0mm | 300mm-2500mm | 2" x 3" | 1.5mm-3.5mm | 300mm-2000mm | 2" x 4" | 2.0mm-4.0mm | 300mm-1828mm | 3" x 3" | 1.0mm-4.5mm | 300mm-2500mm | 3" x 4" | 1.5mm-4.5mm | 300mm-2000mm | 4" x 4" | 1.0mm-4.5mm | 300mm-2500mm | 5" x 5" | 2.5mm-4.5mm | 300mm-2500mm | 6" x 6" | 2.5mm-4.5mm | 300mm-2500mm | Technical Note: 1 - Standard roll length: 15.24m, 30m, 50m.

2 - Special sizes available at request.

3 - Packing: in waterproof paper in rolls.

Custom packing available at request.

4: AnPing YaQi Wire Mesh Factory Can supply Free sample 5: Can accept test before the goods loaded | - - - -
