Compound Salt Spray Cct Corrosion Test Chamber - China

Compound Salt Spray (CCT) Corrosion Test Chamber Composite salt spray (CCT) corrosion test chamber is also called cyclic corrosion test chamber or CCT salt spray test chamber.

Some industrial products require exposure to repeated cycles of salt spray, high humidity, and low humidity drying and standing.

These tests were initially manually switched between several test boxes.

The multifunctional compound salt spray box solves this problem well, and realizes these cycle tests automatically in one box.

Standards compliant: GB/T 1771-2007 "Paints and varnishes - Determination of resistance to neutral salt spray"

GB/T 31588.1-2015/ISO11997-1: 2 005 "Paints and varnishes - Determination of cyclic corrosion resistance - Part 1: Wet (salt spray)/dry/moisture"

GB/T 2423.17-2008 "Environmental test of electrical and electronic products - Part 2: Test method Test Ka: Salt spray"

GB/T 2423.18-2000 "Environmental test of electrical and electronic products - Part 2: Test Test Kb: Salt spray, alternating (sodium chloride solution)"

GB/T 2423.3-2006/IEC6008-2-78- 2001 "Environmental test of electrical and electronic products - Part 2: Test method Test Cab: Constant damp heat test"

GB/T 5170.8-2008 "Test methods for environmental test equipment for electrical and electronic products--Salt spray test equipment"

GB/T 10125-1997 "Artificial Atmosphere Corrosion Test Salt Spray Test"

GB/T 10586-2006 "Technical Conditions for Damp Heat Test Chamber"

GB/T 10587-2006 "Technical Conditions for Salt Spray Test Chamber"

GB/T 10593.2-2012 "Measurement methods for environmental parameters of electrical and electronic products - Part 2: Salt spray"

GB/T 12000-2003 "Determination of the influence of plastic exposure to damp heat, water spray and salt spray"

GB/T 20854-2007/ISO14993: 2001 "Corrosion of Metals and Alloys - Accelerated Testing of Cyclic Exposure to Salt Spray, Dry and Wet Conditions"

GB/T 24195-2009/ISO16151: 2005 "Corrosion of metals and alloys - Cyclic accelerated corrosion test under acidic salt spray, "dry" and "wet" conditions Features:

◆ The test chamber is welded with imported CPVC board, the board thickness is 8mm, and the durable temperature is 100℃;

◆ The test box is welded with imported PVC board (Nanya, Taiwan), with a thickness of 6mm and a durable temperature of 85°C;

◆ The inner box of the drying and damp heat control box is made of SUS304# stainless steel, the outer box is made of PVC polyethylene board, and the thermal insulation material is made of polyurethane rigid foam;

◆ The sealing cover of the laboratory is made of imported CPVC board, with internal strengthening treatment, thickness 8mm, and the top is a 100-degree angle sealing cover.

The internal strengthening treatment can effectively prevent condensation water from dripping on the surface of the sample during the test to affect the test results.

At the same time, the box cover is provided with 1 A transparent tempered glass observation window (size is 400mm*400mm)

◆Pressurized air barrel: Made of SUS304# stainless steel, high pressure resistance and best heat preservation effect

◆ Salt water replenishment tank: made of CPVC board, total capacity: 25L PS: (WLJCDM809-W)
