J599Ⅲ Series Expanded Beam Fiber Optic Connector - China

Product Features Comply with the GJB599B (MIL-DTL-38999) Series Ⅲ interface

The outer shell can be made of different materials and coatings to meet different environmental requirements

Five-key positioning with blind mating and error-proof features

Rapid three-start thread connection with an anti-loosening mechanism

The contact components adopt collimating lenses for non-contact connection, making the end face less prone to damage and ensuring high mechanical life; the emitted light spot is large, making it insensitive to dust and environmentally resilient.

Mechanical Properties • Mechanical Life: 2000 cycles of insertion and extraction

• Shock Resistance: 980m/s²

• Vibration Resistance: 10Hz to 2000Hz, with an acceleration of 147m/s²

• Tensile Strength: ≥68N (for single-core cables) Environmental Performance • Temperature Range: -55℃ to +85℃ (based on fiber optic cable temperature)

• Salt Spray: Type K: 500 hours Type F: 48 hours Type W: 500 hours Type MW: 192 hours (acidic atmosphere)

• Fluid Resistance: Resistant to various fuels, coolants, and other oils Optical Performance • Insertion Loss: ≤0.6dB (Multimode), ≤1.2dB (Singlemode) Outline Dimensions of Connectors with Tail Attachments
