Customized Aluminum Alloy And Carbon Fiber Hybrid Electric Bike - China

Model: manglead-10

[Brand] KRISTALL [Model] E5-speed [Net weight] ≈19.5 KG

[Frame] E5 Lightweight Aluminum Alloy/Flat Welding Internal Wiring/Extinction/UV Label

[Handle Set] RS Lightweight Aluminum Anode Reinforced/Straight 680mm/Double Nail Seat Tube 31.6mm

[Pipe clamp] aluminum alloy quick release 34.9

[Front fork] KST aluminum alloy mechanical shoulder control and lockable

HeadsetAluminum alloy CNC, 44mm

DialSHIMANO M310-8 speed

Back DialSHIMANO TZ50

CranksetRS aluminum alloy square hole/single plate 38T with aluminum guard plate

FlywheelDNP-8 speed, rotary, 13-32T

ChainYBN-8S

Bottom AxisKENLI Bearing, BB68mm

BrakeZ.

STAR cable pull mechanical disc brake

HubeRS Lightweight Aluminum Alloy/Pailin Disc Brake

[Rim] Lightweight aluminum alloy double layer with rivets

SpokesShunjiu High Rigidity Round Bar

[Tire] Jianda K1187 or CST, 26"/27.5"/29"*1.95

[Grip cover] Bilateral lock comfortable round

CushionThick and comfortable mountain

PedalsWP-625 aluminum alloy with high lubricity

Line TubeJAGWIRE

[Accessories] Steel back support + tools

***Electric parameters***

Riding ModeElectric power riding (5 gears), pure electric riding (5 gears), pure human riding (8 speeds)

[Endurance mileage] 70-110KM electric-assisted riding, 40-60KM pure electric riding

[Power-assisted speed] 25KMH (If you have special requirements, please contact customer service for details)

[Maximum load] 130KG

[Battery parameters] LH18650 power lithium battery 36V10A, with USB2.0 charging port 5V2A (for mobile phones, etc.

)

Full time4-6 hours

Charging times>1000 times

[Charge protection] Overvoltage/overcurrent/s hort circuit/reverse connection protection, etc.

[Motor parameters] Rear drive, internal speed measurement, 36V250W, brushless DC with teeth, low resistance and low noise

Maximum Torque≈60 N.

M

[Waterproof rating] IP54 (motor)

[Controller] 5-speed intelligent assist control system, integrated IC control

[Instrument category] LCD digital display control

[Display function] speed, mileage, power, gear, fault, etc.

[Setting function] Clear mileage, wheel diameter, etc.

[Waterproof rating] IP6 (instrument)

[Power-assisted sensor] 12 magnetic pulse double Hall, speed type (cadence)

Turn the speed controlThumb finger / stepless speed control

Brake power offElectromagnetic power off brake lever/stop power off

[Speed sensor] Motor built-in Hall speed measurement

Wire connectorFull waterproof quick connector
