China Newly Tech Vacuum Lube Oil Purifier - China

Application:

ZYL vacuum lube oil purifier also can be used as oil filtration systems for turbine oil, gear oil, engine oil, compressor oil, refrigeration oil and other industrial oils, so it is wildly applied in electric power, metallurgy, mining, chemicals, transportation, manufacturing, petroleum, railway etc.

ZYL- vacuum lube oil purifier is the most reliable, versatile, durable, and user-friendly machine in the industry today.

ZANYO outstanding features:

A． Evaporation chamber is horizontal, and oil chamber is vertical, the two chambers are separated, therefore the maximum utilization of degassing chamber space.

B． Unique technology: Atomizer is placed upside down, the oil droplet average diameter less than 60µm, to increase evaporation area and extend the degassing time.

Comparing to the one- vertical chamber machine, ZYL filtration system is 3 -fold and 5-fold quickly and effectively thank old machine.

Features:

1 - “T ” type of the evaporator, enlarged the separating surface and separating time.

2 - Unique and high capacity dehydration, degasification and demulsifying system, which adopts stereo-evaporating technology, enabling fast removal of large water, gas and volatile matter (such as alcohol, gasoline, ammonia, etc.

)

3 - Special polymer materials as filter element with the functions of broken emulsion, dewatering, removing particles.

99.5% of particles over 1.0 micron are removed.

4 - Fully Automatic liquid-level controlling system, defoaming controlling system, pressure protecting system and excellent configuration can ensure operation of the equipment with high performance.

5 - Multi-stages high precision oil filtration systems, large capacity for holding particles, anti-corrosion, good mechanical performance, long lifetime and easy to replace and clean.

6 - An advanced fully automatic temperature controlling system, efficient electric heating system, heating uniformity, less power consumption, safe, and reliable.

7 - Interlocked protective system connects oil pump, heater and liquid level sensor, avoiding blank heating, blank pumping, oil leak and electricity leak.

fault alarm, power off automatically.

8 - Advanced medium cooling system

The final treated oil index:

Item Guarantee indexes

Moisture content ≤20 PPM

Demulsification value New oil≤15min, old oil≤30min

Impurity size ≤1 micron

Gas content ≤0.1%

Technical Data:

Index name unit 10 20 30 50 80 100 125 150 200 300

Capacity L/min 10 20 30 50 80 100 125 150 200 300

Working vacuum Mpa -0.070～-0.099

Working pressure Mpa ≤0.5

Water content ppm ≤20

Demulsifying value Min ≤15/min(GB/F7035)

Cleanness NAS 5

Particles size µm ≤1

Working temperature ℃ 40～70

Continue working time H ≥200

power According to customers’ option

Working noise dB 65

Long-term quality warranty of 2 years.

Optional Parts

PLC control system, dynamic display

Online moisture tester

Frequency changer

Flow meter

Structure: Mobile type, stationary type, trailer, enclosed doors, open
