Zyc Waste Vacuum Cooking Oil Purifier Machine - China

ZYC waste vacuum cooking oil purifier machine

Application:

ZYC vacuum cooking oil purifier can be used for food service industry.

It is a good purification machine for Fry food factory, oil restaurant, cooking oil factory, vegetable oil factory, and waste oil collecting store.

You can choose the stainless steel machine body for food oil purifying.

The cooking oil includes: dirty vegetable oil, trench oil, swill oil, coconut oil, sunflower oil and animal oil etc.

for the coconut oil, we advise you can choose the ZYC-I machine.

ZYC vacuum cooking oil purifier can be used for biodiesel industrial.

It is a good oil filtration machine for purifying the waste oils, then preparing for making biodiesel.

You can choose the carbon steel machine body.

ZYC cooking oil purifier is as the oil filtration machine for purifying cooking oil, dirty vegetable oil, trench oil, swill oil and animal oil etc.

The vacuum cooking oil purifier can removes particles, odor, water, acid and alcohol etc from waste oil effectively and completely, so that the treated oil is clean, limpidity, and good smell.

ZANYO outstanding features:

A.

Evaporation chamber is horizontal, and oil chamber is vertical, the two chambers are separated, therefore the maximum utilization of degassing chamber space.

B.

Unique technology: Atomizer is placed upside down, the oil droplet average diameter less than 50µm, to increase evaporation area and extend the degassing time.

Comparing to the one- vertical chamber machine, ZYC filtration system is 3 -fold and 5-fold quickly and effectively thank old machine.

Machine Features:

1 - Separation system : “T ” type of the evaporator, enlarged the separating surface and separating time.

Adopts the vacuum vaporizing technology to remove water, odor, and alcohol, and volatilization materials to Inhibit acid value and peroxide value increases.

2 - Filtration system: it is composed of vacuum filtration system and pressure filtering system.

Making sure filter size is less than 1 micron.

3 - Heating system: Efficient electric heating system, heating uniformity, less power consumption, safe, and reliable

4 - Protecting system: With interlocked protective system, avoiding blank heating, blank pumping, oil leak and electricity leak.

If there is any fault, machine will be power off automatically.

The final treated oil index:

Item Guarantee indexes

Moisture content ≤10 PPM

Demulsification value New oil≤15min, old oil≤30min

Impurity size ≤1 micron

Gas content ≤0.1%

ZYC Index:

Model ZYC Unit 10 20 30 50 75 100 125 150 200 300

Capacity L/min 10 20 30 50 75 100 125 150 200 300

Working Vacuum Mpa -0.070～-0.099

Working Pressure Mpa ≤0.5

Water Content ppm ≤10

Mechanical Impurities % None

Demulsification Value min ≤8

Impurity Size µm ≤1-3

Gas Content % ≤0.1

Clean Grade NAS ≤6

Working Temperature ℃ 40～70

Power According customers’ option

Long-term quality warranty of 2 years.
