Tobee® 10 8s G Dredge And Gravel Pump With Gearbox - China
price: 30000.00 Dollar US$
Tobee® 10/8S-G Dredge and Gravel Pump with gearbox will be used for River Dredging and Dike Strengthening.
10x8S-G Gravel Pump Wear Parts Design:
Impeller: Front and back shroud expulsion vanes reduce gland pressure and intrusion of high concentrations of solids in the gland area.
Efficiency is maintained by minimizing suction side recirculation.
Specially designed and shaped impeller vanes allow the handling of extraordinarily large particles.
The unique casing design and sealing vanes prevent abrasive solids intrusion at the sealing faces.
Casing: Robust casing has been designed to reduce internal velocities resulting in minimum efficiency loss and improved casing wear life.
The casing is made up of three components to reduce maintenance time and costs associated with a one piece design.
Expeller (Centrifugal Seal): no external sealing water required where applicable.
Stuffing Box: flushed gland sealing with braided packing and a lantern ring
Bearing Assembly: Tobee heavy-duty grease lubricated taper roller bearing assemblies are fitted as standard.
A rigid large diameter shaft with reduced overhang minimises deflection and vibration under all conditions ensuring trouble free operation.
Unusually high service factors enable the assembly to carry all radial and axial thrusts.
Company Contact:
- Posted By: Hebei Tobee Pump Co.,Limited
- Phone: 13315360437
- Address: Shijiazhuang,Hebei province,China, Shijiazhaung , Hebei , China
- Email:
- Website: http://www.tobeepump.com
Published date: December 28, 2021
- Business Description: Hebei Tobee Pump Co.,Limited, is a professional manufacturer in designing and manufacturing Centrifugal Slurry Pumps, Pipes & Fittings, Valves etc.
Our factory is located in the High tech Development Zone, Shijiazhuang City, China.
We specialized in Horizontal slurry pumps, Vertical slurry pumps, Gravel sand pumps, Dredging pumps, Paper pulp pumps, Molten Salt Pumps, End suction pumps, Double suction pumps, Multistage pumps, Boiler feed water pumps, Self priming pumps, Inline centrifugal pumps, Sea water pumps, Chemical pumps, Irrigation pumps, Fire pumps, API 610 centrifugal oil pumps, Sewage pumps, Submersible slurry pumps, Slurry Pump spare parts, Pipes & fittings and Valves in domestic and over 80 countries in the world.
