Tobee® 4x3d Ahr Rubber Material Lined Slurry Pump - China
price: 8000.00 Dollar US$
Tobee® 4x3D-AHR Rubber Lined Slurry Pump is the heavy duty slurry pump handling tough and abrasive duties.
Rubber slurry pumps are widely used for continuous pumping highly abrasive/dense slurries in processes from cyclone feed to regrind, mill discharge, flotation, mine drainage, dredging of settling lagoons and pumping of drilling mud and tailings in minerals plants.
Design Features:
√ Double casings design centrifugal rubber lined slurry pump, wide passage for solids
√ Bearing assembly & frame: Both standard & high capacity types available.
√ A large diameter shaft with a short overhang minimizes deflection and vibration.
√ Heavy duty roller bearing is housed in a removable bearing cartridge.
√ Rubber slurry pump body is fastened with the frame by minimum bolts.
√ Slurry pump impeller adjustment is provided in a convenient position below the bearing assembly.
√ Slurry pump Impeller & liner material: natural rubber etc
√ High efficiency impeller available: up to 86.5% for certain type.
√ Interchangeable wet parts material: High chrome alloy metal: PH: 5-12; natural rubber: PH: 4-12.
√ Shaft seal: Packing seal, centrifugal seal, mechanical seal.
√ Discharge branch: 8 positions in each 45°.
√ Driving type: V-belt, flexible coupling, gearbox, hydraulic coupler etc.
