Tobee E044hs1c23 Gland Assembly Is Used For 6 4eah Slurry Pump - China

Tobee E044HS1C23 Gland Assembly is used for 6/4 EAH, 8/6 EAH Slurry Pumps, and made in C23 (SS316L) material.

The gland packing is a contact-type sealing element.

Compared with other types of shaft seals, they are adjustable and suitable for use with pressures and circumferential speeds higher than those radial shaft seal rings are used for Gland packing

The gland packing's application limit is primarily determined by the extent to which heat developing due to friction can be dissipated.

For heavy-duty gland packings, leakage water is actually pre-cooled by means of an internally cooled shaft protecting sleeve and a cooling jacket.

The packing materials generally employed are braided cords made from asbestos-free yarn such as Ramie, Aramid, PTFE, graphite fibres or cotton, which are processed on special machines to form endless square braids.

The packings can be adjusted and are suitable for higher pressures and circumferential speeds than lip seals.

Different packing variants are used depending on whether the pump is run in suction head or suction lift operation, or whether it handles clean or contaminated fluid.

In the case of positive pressure, the gland packing is equipped with three to five packing rings.

These packing rings are pressed together axially via the gland follower.

As a result they expand radially which means the pressure on the shaft protecting sleeve is increased.

This has an influence on the clearance gap width and the leakage rate at this location.

The radial gap between the shaft protecting sleeve and the packing rings allows fluid to leak to the outside.

This leakage is required to reliably dissipate the heat generated by friction from the gap.

When tightening the gland bolts it is important to find a satisfactory compromise between an acceptable leakage rate and sufficient packing cooling.
