Astm A53 Asme Sa53 Carbon Steel Pipe - China

ASTM A53 (ASME SA53) carbon steel pipe is a specification that covers seamless and welded black and hot-dipped galvanized steel pipe in NPS 1/8″ to NPS 26 - A 53 is intended for pressure and mechanical applications and is also acceptable for ordinary uses in steam, water, gas, and air lines.

A 53 is a general steel pipe spec which covers galvanized pipe and black pipe.

It is available in Type S (seamless), Type E (ERW, electric resistance welded longitudinal seam), and Type F (furnace welded).

A53 pipe comes in three types (F, E, S) and two grades (A, B).

A53 Type F is manufactured with a furnace butt weld or may have a continuous weld (Grade A only)

A53 Type E has an electric resistance weld (Grades A and B)

A53 Grade B Seamless is our most polar product under this specification and A53 pipe is commonly dual certified to A106 B A53 Type S is a seamless pipe and found in Grades A and B) Seamless pipe.

1 - ASTM A53, a general purpose seamless steel pipe, suitable for use in pressure piping systems, pipe piping, and general purpose pipes at temperatures below 350°C.

2 - ASTM A106 seamless steel pipe for high temperature operation, suitable for high temperature.

Corresponds to the national standard No.

20 steel pipe .

ASTM is the standard of the American Materials Association, and it is not the same as the domestic division method, so there is no strict corresponding standard.

There are many different specifications of products under one model, depending on your specific use.

A53 Pipe Materials & Manufacture Steel materials used to create seamless pipe and welded pipe must be produced via open hearth, electric furnace, basic oxygen, or any combination of these processes.

All weld seams in electric-resistance welded A53 Grade B pipe must be heat treated after welding to a minimum of 1, 000°F (540°C) to eliminate untempered martensite.

Product Name Seamless Carbon steel pipe

Size OD 12.7mm-710mm

Thickness 3mm-45mm

Length SRL, DRL, 5.8M, 11.8M

Steel Material ASTM A53/A106, API 5L, EN10216, DN162ASTM A179 A192 A210

Steel Grade Grade A, Grade B, Grade C, X42, X52 - S235JRH, S355, P265 ect.

Process Hot rolled/hot expansion/cold drawn/cold rolled

Usage High temperature service

Surface Bared Black Painting, Galvanized, Coating

Proctor Plastic cap

Package Bundles, Bulk

Inspection With Hydraulic Testing, Ultrasonic testing or X-ray Test
