Sn2401f Dn15 Plastic Lined O Type Ball Valve - China

price: contact company for price

Sn2401f Dn15 Plastic Lined O Type Ball Valve

Products Photos Catalog Sn2401f Dn15 Plastic Photos Catalog

SN2401F series plastic-lined ball valves have excellent corrosion resistance and are separated from the contact parts with the media by fluoroplastic.

PTFE and FEP are mainly selected as fluoroplastic.

They are usually used in occasions where sealing requirements are high and highly corrosive media can be reliably switched on and off.

Plastic Lined O-type Ball Valve TECHNICAL PARAMETERS

Nominal Size DN15~DN250

Pressure Rating PN6/PN10/PN16;CL150(PN20)

Operateing Temperature -30℃~150℃

Characteristics Quickly open

Rangeability /

Seat Leakage Class Zero Leakage

Body Material WCB+F46/CF8+F46/CF8M+F46/ WCB+PFA/CF8+PFA/CF8M+PFA

Trim Material WCB+F46/304+F46/316+F46/W CB+PFA/304+PFA/316+PFA


Seal Material Product lists:

Globe valve

O ball valve

v shaped Ball Valve


Company Contact:


  • Phone: 86 571 81119774

  • Address: SUPCON Park, No.309 Liuhe Road, Binjiang District, Hangzhou , zhejiang , China

  • Email: Email


Published date: February 13, 2020

  • Business Description: Founded in March 1993, SUPCON is one of China's leading manufacturer and supplier of automation and information technology, products and solutions.

    Its automation products and solutions are applied in over 35 countries and regions worldwide.

    Zhejiang SUPCON Fluid Technology Co., Ltd. is an important member of the SUPCON Group.

    Our core products, industrial process control valves (Globe Valve, Ball Valve, Eccentric Rotary Valve and Butterfly Valve).

    Our company has a field experienced and strong technical team, and also committed to the development of stringent complex working condition control valve, to solve high pressure, corrosion, flash, erosion, large differential pressure and a series of technical problems.

    Our company is committed to providing users with international competitiveness of high quality product and comprehensive technical services in oil and refinery, petrochemical, coal chemical, fine chemical, metallurgy and so on.
