Motor Extension Cable - China

price: 1.00 Dollar US$

Motor Extension Cable

Products Photos Catalog Motor Extension Cable Photos Catalog

Motor Extension Cable, 9 Pin Front Rear Wheel Motor Female to Male

Name Large 9 cores motor cable

Model WYT-PFV2-916AT

Inlet/Outlet 9 cores

Rated voltage 60V AC/DC

Rated current power 20A, cable 2A

Withstand voltage 500V

Insulation resistance ≥20MΩ

Contact resistance ≤10mΩ

Mechanical life 200 times

Insertion force ≤100N

Pull out force ≥50N

Working temperature -25℃～+85℃

Protection grade IP66

Dimensions male 16.8mm, female 16mm

Overalllength 88.5mm

Contact element material gold-plating Copper alloy

Wire specification 2.0mm²+0.20mm²

ATINGS/CHARACTERISTICS

UL Recognized

RoHS Compliant

48 V

power 20A, cable 2A Waterproof cable: IP65 Sealed waterproof connectors, sturdy and durable

MATERIAL

WATER PROOF WIRE FEATURES

Most common Y splitter connector cable for Electric bike.

Lenght: can be any length needed.

power 20A, cable 2A

Life: 200 times

9PIN

Waterproof cable: IP65 Sealed waterproof connectors, sturdy and durable

WATER PROOF WIRE ENVIRONMENTS

Ebike motor

Suzhou grand electronic technology co., Ltd. Is a high-tech enterprise that produces advanced waterproof cables.

It is located in dongshan town, wuzhong district, suzhou city, china, in the jiangsu-zhejiang-shanghai economic triangle.

Our honor and company culture.


Company Contact:


  • Phone: 18758486780

  • Address: 3RD FL，NO.10 BLD，51 Fenghuangshan Road, Dongshan Town, Wuzhong District, Suzhou City, Jiangsu Sheng, China

  • Email: Email


Published date: August 17, 2021

  • Business Description: Suzhou Grand Electronic Technology Co., Ltd. is a high-tech enterprise that produces advanced waterproof cables.

    It is located in Dongshan Town, Wuzhong District, Suzhou City, China, in the Jiangsu-Zhejiang-Shanghai Economic Triangle.

    Grand specialized in integrates research and development, production and sales, and its products are used in professional fields such as new energy vehicles, solar energy, aviation, aerospace, medical care, nuclear technology, and military applications.

    Grand has passed the ISO 9001 quality system certification, and its products comply with Chinese and foreign national standards, and have various certificates such as CE, ROSH, etc.

    And it has independently developed a number of patented products and has strong independent development capabilities.
