Motor To Main Power Cable 9 Pin - China
price: 1.00 Dollar US$
Motor to Main Power Cable 9 Pin main cable for electric bike
Name Large 9 Pin motor cable
Model WYT-P-915AT
Inlet/Outlet 9 cores
Rated voltage 60V AC/DC
Rated current power 20A, signal 2A
Withstand voltage 500V
Insulation resistance ≥20MΩ
Contact resistance ≤10mΩ
Mechanical life 200 times
Insertion force ≤100N
Pull out force ≥50N
Working temperature -25℃～+85℃
Protection grade IP66
Dimensions male 14.9mm, female 18.5mm
Overalllength 85mm
Contact element material gold-plating Copper alloy
Wire specification 2.0mm²+0.20mm²
TAGSMotor cablebafang connector
Company Contact:
- Posted By: Suzhou Grand Electronic Tech CO., ltd
- Phone: 18758486780
- Address: 3RD FL，NO.10 BLD，51 Fenghuangshan Road, Dongshan Town, Wuzhong District, Suzhou City, Jiangsu Sheng, China
- Email:
- Website: https://www.szwyte.com/
Published date: August 17, 2021
- Business Description: Suzhou Grand Electronic Technology Co., Ltd. is a high-tech enterprise that produces advanced waterproof cables.
It is located in Dongshan Town, Wuzhong District, Suzhou City, China, in the Jiangsu-Zhejiang-Shanghai Economic Triangle.
Grand specialized in integrates research and development, production and sales, and its products are used in professional fields such as new energy vehicles, solar energy, aviation, aerospace, medical care, nuclear technology, and military applications.
Grand has passed the ISO 9001 quality system certification, and its products comply with Chinese and foreign national standards, and have various certificates such as CE, ROSH, etc.
And it has independently developed a number of patented products and has strong independent development capabilities.
