230v 24v 150va Grewin Waterproof Toroidal Transformer For Led Lighting - China

price: 21.50 Dollar US$

230v 24v 150va Grewin Waterproof Toroidal Transformer For Led Lighting

Products Photos Catalog 230v 24v 150va Grewin Photos Catalog

Name :

230v 24v 150va Grewin Waterproof Toroidal Transformer for LED Lighting Certification: 1 - We have abtained VDE, UL, CE, ISO9000 approval .

we guarantee quality is the first.

2 - Waterproof Transformer's Dimension Sheet:

(Note: Rated 105VA-1000VA for devices 105VA-1000VA watts or less, GWET-105 means 105VA size ) Waterproof Toroidal Transformer Model Power(va) Input Voltage(v) Output Voltage(v)/A GWET-105 105VA A 220-240V 50-60HZ 24V/4.38A B 220-240V 50-60HZ 12V/8.75A GWET-150 150VA A 220-240V 50-60HZ 24V/6.25A B 220-240V 50-60HZ 12V/12.5A GWET-180 180VA A 220-240V 50-60HZ 24V/7.5A B 220-240V 50-60HZ 12V/15A GWET-200 200VA A 220-240V 50-60HZ 24V/8.33A B 220-240V 50-60HZ 12V/16.67A GWET-250 250VA A 220-240V 50-60HZ 24V/10.42A B 220-240V 50-60HZ 12V/20.83A GWET-300 300VA A 220-240V 50-60HZ 24V/12.5A B 220-240V 50-60HZ 12V/25A GWET-350 350VA A 220-240V 50-60HZ 24V/14.58A B 220-240V 50-60HZ 12V/29.17A GWET-400 400VA A 220-240V 50-60HZ 24V/16.67A B 220-240V 50-60HZ 12V/33.33A GWET-450 450VA A 220-240V 50-60HZ 24V/18.75A B 220-240V 50-60HZ 12V/37.5A GWET-500 500VA A 220-240V 50-60HZ 24V/20.83A B 220-240V 50-60HZ 12V/41.67A GWET-600 600VA A 220-240V 50-60HZ 24V/25A B 220-240V 50-60HZ 12V/50A GWET-800 800VA A 220-240V 50-60HZ 24V/33.33A B 220-240V 50-60HZ 12V/66.67A GWET-1000 1000VA A 220-240V 50-60HZ 24V/41.67A B 220-240V 50-60HZ 12V/83.3A 3 - Waterproof outdoor toroidal Transformer's Spcification:

1).

WORKING AND SAFETY PROTEETION Eiectrostatic Shield Magnetic Shield

√ TemperatureProtection OverCurrent Protection 2).

INSULATION

Insulation resistance test(type test): Pri.

~sec.

500V DC 100 MΩMIN.

HI-POT TEST(100% test): Pass ourdielectric strength test, without any breakdown

Pri.

~sec.

AC 3.8kV for 5 seconds (leakage current 5mAMAX) 3).

TEMPERATURE RISE

Ta=25ºCTest by resistance method At rated load PRI.

& SEC.

WINDINGS'TEMPERATURE RISE 75ºCMAX.

4).

MAJOR MEASUREMENT FACILITIES: HI-POT TESTER: CJ2670

INSULATION-RESISTANCE METER: ZC-7

VOL TMETER: T19-V

DC-RESISTANCE METER: QJ44

AMPEREMETER: T19/1-A 5).

MAIN PARAMETERS:

Input Voltage: AC 220V 230v 110v (Define the voltage) Output voltage: AC 12V / 24V (Define the voltage)

Power range: 105VA-1KVA 6) Waterproof toroidal Transformer's materials:

* Annular core: Cold rolling directional silicon steel * Insulation protection: Mylar

* Core Insulation: Polyester 7C

* Primary/Secondary Winding: Enamelled copper wire

* Terminal cannula: PVC canula

* Termial uderlay: Polyester 19C

* Temperature Protection: Thermal Switch

* Pri.

Insulation: Polyester 7C

* Insulation protection: Mylar

* Coating insulation: Polyester 5C

* Lead: UL WIRE

* Potted resin: Potted resin

* Body: PP+GFRP 7)Standard conditions and components: * Transformer should meet "Short-circuit-proof safety isolating transformer (inherently

or non-inherently) IEC 61558-2-6: 09" * Thermal Switch 17AM 211 120°C Sensata Technologies or equivalent (UL E15962) * Thermal Fuse A7-5A-F 5A/138°C Aupo Electronics or equivalent (UL E140847) * Transformer is double insulated (Class II) with Insulation Class B 120°C * Insulation tests 500VDC 100M ohm min and 4kV for 5 seconds at 5mA max leakage current 4 - Application: Garden light LED underwater lamp LED Ground light

Outdoor power Supply

Humidifier

Swimming pool 5 - Advantages:

100% copper wire made

Toroidal style

plastic cover : ABS fire Material of withstand high temperatures Epoxy resin high performance insulation Anti-corrosion, waterproof performance RELATED UNDERWATER TOROIDAL TRANSFORMERS: a.

Power range: 10VA-25VA PCB Encapsulated Transformer

b.

Power range: 10VA-6KVA Center bolt EncapsulatedTransformer: Contact Information: Amy

Tianjin Grewin Technology Co., Ltd. tel: 86-22-84943756

MT: 86-18920139710


Company Contact:


  • Phone: +862284943756

  • Address: RM1013 2#Building MeiNian Plaza No.16 DongTing Road HeXi Distr, 300222 Tianjin China., Tianjin , TianJin , China

  • Email: Email


Published date: July 31, 2018

  • Business Description: Tianjin Grewin Technology Co.

    Ltd. In Tianjin City which is very close to XinGang Port and BinHai International Airport, which provide timely and convenient access to transportations for customers.

    Its a professional leading and a main exporter of a wide variety of electronics components in north of China.

    All of our products stand for top quality in this industry and are enjoying very high honor.

    We have abtained ISO90001, CE, SGS approval and IEC test report.

    Our core business are including following:

    1 - Toroidal Transformers

    2 - Current Transformers

    3 - EI laminated Transformers

    4 - Ferrite Core Transformers

    5 - Monitoring Devices

    6 - Power Testing

    7 - Chokes Coil

    All staff in our company would like to appreciate for your attention to our products.

    Welcome to give us your valuable suggestions about products and services.

    You can be our sole agent in your country and benefit from more preferable prices.

    OEM orders are welcome.
