40ka 12v 2p Street Light Dc Surge Protector - China
price: contact company for price
40ka 12v dc 2p street light Dc surge protector This surge protective device( hereinafter referred to as SPD) are suitable for AC 50/60Hz, rated voltage up to 380v IT, TT, TN-C, TN-S, TN-C-S and other power supply system, it protect to indirect and direct lightning effect or other transient over voltage SPD design according with GB18802.1/IEC61643-1 standard.
Specification details:
Model PQ-12DC
Poles 2P
Max.
continious working voltage(Uc) 15V DC
Nominal discharge current(In) 20kA
Max.
discharge current(In) 40kA
Voltage protection level(Up) 0.4kV
Matched circuit breaker/Fuse 32A
Response time <25ns
L/N wire section 2.5mm2
PE section 4mm2
Installation DIN rail
Case protection degree IP20
Operating state/ fault indication Green/ Red
Remote signal function Can also picking
SPD type T2
Company Contact:
- Posted By: Zhejiang Pingqi Electric Co., Ltd.
- Phone: 15558881002
- Address: No. 159 Changjiang road, Liushi town, wenzhou , zhejiang , China
- Email:
- Website: https://www.pq-electric.com
Published date: October 5, 2019
- Business Description: Our Zhejiang Pingqi electric Co., Ltd. Has 7 years manufacturer and export experience.
Exported to 17countries, gained high reputation from overseas customer.
CE certificate gained.
We supply pure sine wave power inverter, surge protector, DC circuit breaker, DC fuse, MC4 connector, DC isolator, MPPT solar controller and other solar items with high quality and competitive price.
OEM and ODM service supply.
We put quality on the top priority, and strictly control on every procedure.
If you are interested in our products or customized service, kindly feel free to contact us.
We'll be pleased to supply you all the best.
