60w 24v 2500ma Waterproof Strip Power Supply - China

price: 10.00 Dollar US$

60w 24v 2500ma Waterproof Strip Power Supply

Products Photos Catalog 60w 24v 2500ma Photos Catalog

Model: APMS-60-24

Technica l Specs:

Output Parameters

Rated Output voltage: 24VDC

Rated Output Current: 2.5A

Rated Output Power: 60W Max

Efficiency>90%

Lin e Regulation: ±0.5%

Load Regulation: ±1.5%

Voltage tolerance: ±3% 2 - Input Parameters

Rated Input voltage: 200-277VAC

Input voltage range: 176-305VAC, 47-63hz

Input Current Max: 0.5A

Inrush Current<20A

Power Factor>0.95

THD<15% 3 - Protection

Overload

Short Circuit 4 - Environment

Operating Temperature range: -40 to +80℃

Storage Temperature range: -45 to +80 ℃

Humidity: 10～95%

Waterproof Level: IP67 5 - Safety Standards

UL8750, IEC/EN61347-1, EN61347-2-13, EN62368, GB19510.1, GB19510.14, IP67 Approved

Withstand voltage: I/P-O/P: 3KV EMI, EMS

EN55015(CISPR15), GB17743, EN61000-3-2, Class C, EN61000-4-2, 8KV air ; Level 2, 4KV contact, EN61000-4-3, EN61000-4-4, EN61000-4-5, 4KV/Line-Line 6KV/Line-Earth, EN61000-4-6 6 - Others

MTBF>200Khours

Dimension: 115(L)*64 (W)*37(H)mm

Packing: 0.55KG/PC, 350 x 310 x 260 mm, 24pcs /14.7Kg /0.02CBM/CTN


Company Contact:


  • Phone: 008618625298070

  • Address: no8,huashan road, xinbei area, changzhou , jiangsu , China

  • Email: Email


Published date: January 12, 2021 - Modified date: January 12, 2021

  • Business Description: Research and development is our strong strength we can realize your ideas to real products.

    Covered with modern production facilities, professional labors, strictly QA/QC inspectors, we are striving to provide the best quality and most durability products.

    All of our products Meet IEC60950,UL60950,EN55015, EN61347,EN6100-3-2 quality standards.

    Exported to over 15 countries with great reputations.
