Electric Switching Power Supply Transformer Toroidal Ferrite Core 749196108 - China

749196108 Switch Mode Transformer for Switching Power Electric Transformer Transformer Electrical Properties: - - - - Properties | Test conditions | | Value | Unit | Tol.

| Inductance Base | 100 kHz/ 100 mV | LBASE | 224.6 | H | 35% | Turns Ratio | | n | 1: 1: 1: 1: 1: 1 | | | Voltage-Second Base | | Udt Base | 49.3 | Vs | max.

| Rated Current Base | T = 40 K | IR BASE | 0.5 | A | typ.

| Saturation Current Base | |L/L| < 10 % | ISAT BASE | 0.04 | A | typ.

| DC Resistance Base | @ 20 C | RDC BASE | 344 | m | max.

| Leakage Inductance Base | 100 kHz/ 100 mV | LS BASE | 0.3 | H | typ.

| Insulation Test Voltage | N1, 2, 3 => N4, 5, 6 | UT 1 | 1500 | V (AC) | | Insulation Test Voltage | N1 => N2, 3; N2 => N3 | UT 2 | 1000 | V (AC) | | Insulation Test Voltage | N4 => N5, 6; N5 => N6 | UT 3 | 1000 | V (AC) | | - - - - General Information: It is recommended that the temperature of the component does not exceed +125C under worst case conditions # Operating Temperature -40 C up to +125 C # Storage Temperature (in original packaging) -40 C up to +85 C # Test conditions of Electrical Properties: +20C, 33% RH if not specified differently 749196108 Switch Mode Transformer for Switching Power Electric Transformer D Electrical Properties: 749196108 Switch Mode Transformer for Switching Power Electric Transformer HOW TO ORDER 1 - Please send me your datasheet or part number you need.

2 - We will offer the replacement quotation for your reference 3 - The free samples are available for your approval.

4 - After sample testing, we will step into the mass order.

5 - The Proforma Invoice will send for your confirmation 6 - After the goods finished, we send the goods to you and tell you the tracking number.

7 - We will track your goods until you receive the goods.

Remarks: 1 - Sample orders are avaliable.

2 - Price is negotiable for orders of large quantity.

3 - Customized orders (OEM/ODM orders) are avaliable.

4 - Contact us for available flavors list.

International Certifications: 1 - ISO9001: 2008 2 - UL 3 - Reach 4 - RoHs Our service: 1 - 100% tested before shipping 2 - Have alternative for Halo, Pluse, Wurth, We-online, Chilisin, CoilcraftSame quality but better price 3 - Free sample available 4 - Provide new design for customer

Company Contact:

• Posted By: SHAREWAY TECHNOLOGY CO., LTD.

• Phone: 86-0755-32932627

• Address: C711 HUAQIAOXINCUN, MINZHI TOWN , LONGHUA NEW DISTRICT , 518131 , SHENZHEN ,CHINA, Shenzhen , guangdong , China

• Email:

• Website: https://www.smpsflybacktransformer.com

• Business Description: Established in 1998, we have around 500 staff at present.

  With the abundant productive capacity , we are able to delivery the goods within the short time.

  Moreover, we can provide the professional complete solution for PoE appliication.
