Famale Rj45 Modular Jack J1006f01pnl For Adsl Modems Lan On Motherboard - China

J1006F01PNL RJ45 Modular Jack for ADSL modems / LAN-on-Motherboard Product Description: 100 Base-TX (Fast Ethernet) RJ45 1x1 Tab-UP with LEDs 8-pin (J1 series) and 6-pin (JP series) integrated magnetics connector, designed to support applications, such as ADSL modems, LAN-on-Motherboard, and Hub and Switches.

Features and Benefits: # RoHS peak wave solder temperature rating 260C Suitable for CAT 5 & 6 UTP cable or better # Meets IEEE 802.3 specification # 350H minimum OCL with 8mA bias current # High performance for maximum EMI suppression Electrical Specifications @ 25C - Operating Temperature 0 C to 70C 1 - Part number: J1006F01PNL 2 - NO.

of ports: 1*1 port 3 - Turns Ratios: # TX: 1CT: 1CT # RX: 1CT: 1CT 4 - EMI Fingers: NO 5 - LEDs L/R: G/Y 6 - Insertion Loss (dB TYP): # 1-65 MHz: -1.0 7 - Return Loss (dB TYP) 100 (15) # 1-10 MHz: -20 # 10-30 MHz: -16 # 30-60 MHz: -12 # 60-80 MHz: -10 8 - Crosstalk (dB TYP): # 1-30 MHz: -40 # 30-60 MHz: -35 # 60-100 MHz: -30 9 - Common Mode Rejection (dB TYP) # 1-50 MHz: -30 # 50-150 MHz: -20 10 - Hipot (Vrms): @60Hz 1MIN # 1500 J1006F01PNL RJ45 Modular Jack for ADSL modems / LAN-on-Motherboard J1006F01PNL RJ45 Modular Jack for ADSL modems / LAN-on-Motherboard HOW TO ORDER 1 - Please send me your datasheet or part number you need.

2 - We will offer the replacement quotation for your reference 3 - The free samples are available for your approval.

4 - After sample testing, we will step into the mass order.

5 - The Proforma Invoice will send for your confirmation 6 - After the goods finished, we send the goods to you and tell you the tracking number.

7 - We will track your goods until you receive the goods.

Remarks: 1 - Sample orders are avaliable.

2 - Price is negotiable for orders of large quantity.

3 - Customized orders (OEM/ODM orders) are avaliable.

4 - Contact us for available flavors list.

International Certifications: 1 - ISO9001: 2008 2 - UL 3 - Reach 4 - RoHs Our service: 1 - 100% tested before shipping 2 - Have alternative for Halo, Pluse, Wurth, We-online, Chilisin, CoilcraftSame quality but better price 3 - Free sample available 4 - Provide new design for customer HOW TO ORDER 1 - Please send me your datasheet or part number you need.

2 - We will offer the replacement quotation for your reference 3 - The free samples are available for your approval.

4 - After sample testing, we will step into the mass order.

5 - The Proforma Invoice will send for your confirmation 6 - After the goods finished, we send the goods to you and tell you the tracking number.

7 - We will track your goods until you receive the goods.

Remarks: 1 - Sample orders are avaliable.

2 - Price is negotiable for orders of large quantity.

3 - Customized orders (OEM/ODM orders) are avaliable.

4 - Contact us for available flavors list.

International Certifications: 1 - ISO9001: 2008 2 - UL 3 - Reach 4 - RoHs Our service: 1 - 100% tested before shipping 2 - Have alternative for Halo, Pluse, Wurth, We-online, Chilisin, CoilcraftSame quality but better price 3 - Free sample available 4 - Provide new design for customer

Company Contact:

• Posted By: SHAREWAY TECHNOLOGY CO., LTD.

• Phone: 86-0755-32932627

• Address: C711 HUAQIAOXINCUN, MINZHI TOWN , LONGHUA NEW DISTRICT , 518131 , SHENZHEN ,CHINA, Shenzhen , guangdong , China

• Email:

• Website: https://www.smpsflybacktransformer.com

• Business Description: Established in 1998, we have around 500 staff at present.

  With the abundant productive capacity , we are able to delivery the goods within the short time.

  Moreover, we can provide the professional complete solution for PoE appliication.
