Four Circuit Monopole Transmission Tower - China

“four-circuit monopole transmission tower” refers to a single, tall, and slender tower designed to support four separate electrical circuits.

These towers are used in the transmission of electrical power over long distances.

The monopole design means that the tower is constructed as a single, sturdy pole, which is often preferred for its smaller footprint and less visual impact compared to traditional lattice towers.

This makes them particularly suitable for use in areas where space is limited or where a more aesthetically pleasing appearance is desired.

Product Four-circuit monopole transmission tower

Shape Polygonal or Conical

Material Normally Q345B/A572, Minimum Yield Strength ≥ 345 N/mm² Q235B/A36, Minimum Yield Strength ≥ 235 N/mm².

OR Q420 Q460 ASTM A572 GR65, GR50, SS400

Electric Voltage 4kv, 6kv, 10kV, 33kv, 35kv, 65kv, 66kv, 110kv, 132kv, 220kv, 230kv, 380kv etc.

Surface treatment Hot dip galvanized Following ASTM A 123, BS729 or as client required.

connection Slip joint, flanged connected

Standard ISO 9001: 2008

Welding Standard AWS (American Welding Society ) D 1.1

Production Process Raw material test → Cutting →bending →Welding (longitudinal )→Dimension verify →Flange welding →Hole drilling →sample assemble → surface clean→ Galvanization or powder coating, painting →Recalibration →Packages

Packages Packing with plastic paper, bundle, wooden box or steel box or according to client’s request.

Deshi Tower specializes in the design, manufacture, and construction support of transmission towers, communication towers, steel structures, and observation towers.

Transmission tower design adheres to ASCE/SEI standards.

Telecommunication tower design follows ANSI/TIA-222 standards.

We are not just manufacturers and suppliers, but also your technical support and partners.
