Fuji Nxt Pick And Place Machine - China

Fuji NXTⅡPick and Place Machine

H12S: 0402 ~ 7.5mm x 7.5mm

H04: 6, 000 cph

2MII Base: 740 (L) x 1934 (W)

Product description: Fuji NXTⅡ Pick and Place Machine INQUIRY

fuji nxtⅡ pick and place machine Products Description: M3 II / M6 II: 48mm x 48mm ~ 510mm x 534mm (double handling rail)

48mm x 48mm ~ 610mm x 534mm (single transport track)

M6 IISP: 48mm x 48mm ~ 510mm x 520mm (double handling rail)

48mm x 48mm ~ 610mm x 520mm (single handling track) Component Type:

M3 II: MAX 20 (8mm tape conversion)

M6 II / M6 IISP: MAX 45 (8mm tape conversion)

Mounting accuracy:

H12S / H08 / H04 / OF: ± 0.05mm (3 sigma) cpk≥1.00

H01 / H02 / G04: ± 0.03mm (3 sigma) cpk≥1.00

GL: ± 0.10mm (3 sigma) cpk≥1.00 Production capacity: H04: 6, 500 cph; H01: 4, 200 cph; G04: 6, 800 cph; OF: M3 II not mountable / M6 II 3000 cph; GL: 16, 363 dph (0.22 sec / dot)) H04: 6, 000 cph; H01: 3, 500 cph; G04: 5, 100 cph; OF: 2, 800 cph, GL: 16, 363 dph (0.22 sec / dot)) Object components:

H12S: 0402 ~ 7.5mm x 7.5mm high: MAX 3.0mm

H08: 0402 ~ 12mm x 12mm high: MAX 6.5mm

H04: 1608 ~ 38mm x 38mm high: MAX13mm

H01 / H02 / OF: 1608 to 74 mm × 74 mm (32 mm × 180 mm) Height: MAX 25.4 mm

G04: 0402 ~ 15.0mm x 15.0mm high: MAX 6.5mm Component Supply:

Smart feeder: corresponding to 8, 12, 16, 24, 32, 44, 56, 72, 88 mm width of the tape

Material feeder: 4≤ element width≤15mm (6≤ tube width≤18mm), 15≤ element width≤32mm (18≤ tube width≤36mm) Tray unit: 135.9X322.6mm (JEDEC standard) (Tray unit M), 276X330mm, 138X330mm (Tray unit LT) Machine size:

2MII Base: 740 (L) x 1934 (W)

4M II Base: 1390 (L) x 1934 (W)

H: 1474 mm (M3 II) 1476 mm (M6 II / M6 IISP) Keywords: China reflow oven, Pick and place machine factory, China chip mounter, SMT chip mounter Manufacturer, Lead Free Reflow Oven factory, wave soldering machine manufacturer, pick and place machine supplier.

Flason Electronic Co., ltd provide a full smt assembly line solutions, including Lead free reflow oven, wave soldering machine, SMT pick and place machine, smt stencil printer, PCB conveyor manufacturer, PCB unloader, chip mounter, SMT AOI machine, SMT SPI machine, SMT X-Ray machine, SMT assembly line equipment, PCB production Equipment smt spare parts etc any kind SMT machines you may need, please contact us for more information: wechat whatsapp: 008613691605420, Skype: flasonsmt, Email: sales@flason-smt.

com FAQ 1) This is the first time I use this kind of machine, is it easy to operate? There is English manual or guide video that show you how to use machine.

If you still have any question, please contact us by e-mail / skype/ phone /trademanager online service.

2) If machine have any problem after I receive it, how can I do ? Free parts send to you in machine warranty period.

If the part is less than 0.5KG, we pay the postage.

If it exceeds 0.5KG, you need to pay the postage.

3) MOQ ? 1 set machine, mixed order is also welcomed.

4) How can I buy this machine from you? ( Very easy and flexible !) A.

Consult us about this product on line or by e-mail.

B.

Negotiate and confirm the final price, shipping, payment methods and other terms.

C.

Send you the proforma invoice and confirm your order.

D.

Make the payment according to the method put on proforma invoice.

E.

We prepare for your order in terms of the proforma invoice after confirming your full payment.

And 100% quality check before shipping.

F.

Send your order by air or by sea.

5)Why choose us ? A.

Gold supplier on Alibaba ! B.

Trade assurance to US$54, 000 ! C.

Best price & Best shipping & Best service !
