Full Automatic Zipper Cutting Machine Lm 100 - China

Model: LM-100 Control Model: RAM control system

Blade: white steel Motor: 57 motor Available Width: 0.1 - 100 mm

Available Length: 1 - 100m

Speed: 120 pcs/min

Accuracy: 0.1mm

Power Supply: AC110V 60Hz / AC220V 50Hz 250W

Measurement: (L)360*(W)300*(H)350mm Weight : 30 Kg

Display: LCD

Operation Language: English or Chinese * High speed: It can cut 150 cut per minute.

(50mm long) Cutter speed adjustable, Electric operation: It works electrically only by setting length and quantity * Arbitrary length and speed continuously adjustable * Automatic grouping accrued and total cumulative count * Batch pause and delay time can be set * Lack of material automatic shutdown, unattended * Can cut a variety of automatic cutting tubular strip material; * High-speed stepper motor precisely controlled pipe cutting & tape length; tape length, speed adjustable;

With LCD screen display, it is simple and convenient to operate.

This machine can be used to automatically cut any kinds of tubular, ribbon, thread-like material * Cutter time protection; total set; points to set; points to pause time adjustable;

* Available in a variety of manual operation, convenient debugging; * LCD large screen visual display, operation simple and convenient;

This machine changed a cutter mould .

It can cut different tube.

Application: Magic sticker, cotton belt, elastic belt, plastic belt, zipper, PVC tube, heat shrink tubing, silicone tube, glass fiber tube, Teflon tube, cable, small wires, conductive fabric / foam, battery separators nickel film, diffusion film, reflective film, double sided tape, Mylar, insulation paper, PE, copper / aluminum foil, cable, release paper cut copper, aluminum, plastic film, heat shrink tubing, PVC pipe, infusion tube, insulation paper, mica, adhesive paper, electrodes, conductive fabric / foam, double-sided tape, heat shrink tubing, nickel plate, pole piece, very ears, insulating paper, Mylar film, barley paper, Pakistan fast paper, polyimide tape (KAPTON), copper / aluminum foil, metal foil, cable, small wires, leather, paper, conductive fabric / foam, acetate cloth, PET, non-woven, insulation paper, EVA, rubber mats, webbing, belts, colored tape, plastic leatherback sea cotton, copper / aluminum foil, a variety of adhesive tape, flexible circuit boards, ect.

All kinds of Silicone tube, Plastic Tube, Medical tube, Yellow wax tube

Feature: Heavy duty, high speed, high accuracy, designed for cutting non-adhesive materials.
