Ge Kts 250 16 Video Distribution Amplifier - China

price: 12000.00 Dollar US$

Ge Kts 250 16 Video Distribution Amplifier

Products Photos Catalog Kts 250 Video Photos Catalog

GE KTS-250-16 video distribution amplifier DESCRIPTION The KTS-250-16 is a video distribution amplifier that features eight groups of input/output channels.

Each group can be configured as a single 1x8 video distribution amplifier or two 1x4 video distribution amplifiers.

This enables users to set multiple configurations from 8 to 16 inputs by up to 64 outputs.

Each output provides unity gain into a 75 ohm load, ensuring that the output signal is equal to that of the input.

Unused outputs self terminate.

SPECIFICATION Inputs：Up to 16 composite video 1 V pk-pk Outputs：Up to 64 composite video 1 V pk-pk Impedance：75 ohm, inputs and outputs Bandwidth：16 MHz S/N ratio -75 dB RMS typical Crosstalk：-85 dB typical Gain (into a 75 ohm load)：0 dB ±0.5 dB typical Differential gain：0.5% typical Differential phase 0.5° typical


Company Contact:

  • Posted By: ZH

  • Phone: 15305925923

  • Address: Jimei North Road, Jimei District, China, XiaMen , China

  • Email: Email


Published date: September 3, 2024

  • Business Description: We are located in the beautiful Fujian Province of China, with professional products and services and adequate inventory.

    Specializing in shipbuilding, chemical, petroleum, storage, natural gas, steel, subway and a series of chemical core equipment products.
