General Purpose Relays 5v G5rl 1a E Ln Dc24 - India

price: contact company for price

General Purpose Relays LowNoise/Profile 16A SPSTNO Hi-capacity 5V : - G5RL-1A-E-LN-DC24

FEATURES: -

• Low profile: 15.7 mm in height

• Creepage distance 8mm between coil and contacts

• 10 kV Impulse withstand voltage

• Models with AC coil available.

• High-Inrush model available (Inrush peak currents up to 100 A)

• Low Noise model available (Approx.

10 to 20 dB less sound pressure than standard G5RL-Series Relays)

• RoHS Compliant

DESCRIPTION: -

Product Category: General Purpose Relays

Manufacturer: Omron

RoHS: RoHS Compliant Details

Coil Voltage: 24 VDC

Contact Form: SPST (1 Form A)

Contact Current Rating: 16 A

Mounting Style: Through Hole

Coil Termination: Solder Pin

Coil Resistance: 443 Ohms

Coil Current: 28.3 mA

Contact Material: Silver Alloy (Ag)

Brand: Omron Electronics

Height: 15.7 mm

Length: 29 mm

Packaging: Bulk

Power Consumption: 750 mVA

Series: G5RL

Factory Pack Quantity: 100

Width: 12.7 mm

Part # Aliases: 667455 G5RL-1A-E-LNDC24 G5RL1AELN24DC
