Gold Silver Platinum Laser Welding Machine Separate 1064 Nm For Diamond Tools - China

Gold Silver Platinum 1064nm Laser Welding Machine Separate For Diamond Tools Introduction: 200W Spot Welding Machine is used for the welding of LED illuminated billboard, exterior/interior signs, branding, door plate that made of aluminum, S/S, iron, galvanized sheet, titanium, brass, copper, and etc.

Laser beam with high energy melts two metal sheets and combine them together without feeding any soldering materials.

From any aspect, laser welding is the best solution and the greenest.

Application for the machine The welding materials of laser mold welding machine are very extensive, including: cold high alloy steel, hot forging high alloy steels, nickel contained tool steel, high quality steel, copper alloys, beryllium copper, high toughness aluminum alloy and other metal materials.

Laser mold welding machine is applied in mold making and molding industry, such as digital products, mobile phones, toys, cars, motorcycles, etc .

Through the repairing of the mold, the original mold can be fully used, greatly saving the production cost and improving the work efficiency.

Features: 1 - Red light spot fast positioning, CCD display, microscope optional 2 - High working speed: 6 times faster then traditional TIG or MIG welding 3 - Slight distortion and less heating affect.

4 - Capable of partial heating process.

5 - Able to deal with complex, profiled, or tiny letters.

6 - Low noise and no pollution.

7 - Ultrafine positioning rod makes corner welding easier without changing position 8 - Laser cavity can move in all directions manually in order to weld letters of different size and in different shape 9 - Parameter setting is very easy; up to 10 sets of parameters can be memorized for different application Technical Parameters: - - - -

Model No.

| LX-D13 | Laser Power | 200W | Laser Source | Pulsed Nd: YAG | Output Optical Path | Single Path(standard) | Laser Wavelength | 1064nm | Single Pulse Energy | 80J | Working Table Scale | 750*1000mm | XYZ Stroke | X=700mm, Y=150mm, Z=200mm(manual) | Power Supply | 220V10%, 50/60Hz | Power Consumption | 6KW | Beam Diameter | 0.1~3.0mm | Pulse Width | 15ms | Pulse Frequency | 1-50Hz | Focal Length | 150mm/200mm | Cooling System | water cooling | Observation system | CCD camera | Packaging dimensions | 1160*610*1150mm | Machine Dimensions | 1420*870*1100 mm | Gross weight | 319kg | - - - -

Company Contact:

• Posted By: Wuhan Linxuan Laser Co., Ltd

• Phone: 86-27-87436808

• Address: ROOM 601,NO. 20 BUILDI NG,GUANGGU NEW POWER I NDUSTRIAL PARK,GUANGGU  SECOND ROAD NO.219,JIAN GXIA DISTR, WUHAN , hubei , China

• Email:

• Business Description: Wuhan Linxuan Laser Co., Ltd is a high-tech enterprise in Wuhan East Lake Development Zone , we are specializing in producing, developing and selling laser marking machine, laser welding machine, laser cutting machine, etc.

  It is Chinese industrial laser processing equipment pioneer.
