H5201nl Ethernet Isolation Transformer 1000base T For Thru Hole Pcb - China

price: check with company for price

H5201NL 1000Base-T Ethernet Magnetic Transformers For Thru-Hole PCB Special Features: 1 - RoHS COMPLIANT 2 - PLASTIC : THERMOSET PLASTIC MATERIAL WITH FLAMMABILTY RATING UL 94V-0 OR BETTER.

3 - SOLDERABILITY: CONFORMS TO ANSI/J-STD-002, IPC/EIA J-STD-003A.

4 - OPERATING TEMPERATURE: 0 TO 70 5 - STORAGE TEMPERATURE : -20 TO +125 6 - JEDEC MOISTURE: LEVEL 1 - 7 - DIMENSIONS ARE IN INCHES WITH THE FOLLOWING TOLERANCES: .

XX = .

0.1 .

XXX = .

005 ELECTRICAL CHARACTERISTICS AT +25 UNLESS OTHERWISE SPECIFIED (FOR REFERENCE ONLY, USED FOR CUSTOMER INFORMATION.

) 1 - OPERATING TEMP : 0 TO 70 2 - TURNS RATIO : 1: 1 2% 3 - POLARITY : PER SCHEMATIC 4 - INSERTION LOSS: 100KHz - 1 - 25 MHz -1.2 dB MAX - -0.2 - 0.002*f 1.4 dB MAXIMUM 5 - RETURN LOSS (Z OUT = 100 OHM 15% ) .

1 - 40 MHz 40 - 100 MHz -16 dB MIN -10+20 * LOG10 ( f/80 MHz ) dB MINIMUM 6 - INDUCTANCE ( OCL ) (MEDIA SIDE, 0-70) 350uH MIN (MEASURED AT 100KHz, 100 mVRMS AND WITH 8 mA DC BIAS) 7 - CROSSTALK, ADJACENT CHANNELS 1 MHz 10 - 100 MHz -50 dB MIN +55+22*LOG10 ( f/80 MHz ) dB MINIMUM 8 - COMMON MODE REJECTION RATIO 2 MHz 30 - 200 MHz -50dB MIN -15 + 20*LOG10 ( f/80 MHz ) dB MINIMUM 9 - DC RESISTANCE 1/2 WINDING .

65 OHMS MAXIMUM 10 - DC RESISTANCE IMBALANCE 0.65 OHMS MAXIMUM ( CENTER TAP SYMMETRY ) 11 - INPUT - OUTPUT ISOLATION 1500 VRMS MINIMUM AT 60 SECONDS H5201NL 1000Base-T Ethernet Magnetic Transformers For Thru-Hole PCB PRODUCT PICTURE H5201NL 1000Base-T Ethernet Magnetic Transformers For Thru-Hole PCB HOW TO ORDER 1 - Please send me your datasheet or part number you need.

2 - We will offer the replacement quotation for your reference 3 - The free samples are available for your approval.

4 - After sample testing, we will step into the mass order.

5 - The Proforma Invoice will send for your confirmation 6 - After the goods finished, we send the goods to you and tell you the tracking number.

7 - We will track your goods until you receive the goods.

Remarks: 1 - Sample orders are avaliable.

2 - Price is negotiable for orders of large quantity.

3 - Customized orders (OEM/ODM orders) are avaliable.

4 - Contact us for available flavors list.

International Certifications: 1 - ISO9001: 2008 2 - UL 3 - Reach 4 - RoHs Our service: 1 - 100% tested before shipping 2 - Have alternative for Halo, Pluse, Wurth, We-online, Chilisin, CoilcraftSame quality but better price 3 - Free sample available 4 - Provide new design for customer
