High Frequency Desktop Laser Welding Machine 220v 50hz For Jewelry Gold - China
price: contact company for price
High Frequency Desktop Led Electrode Plasma Laser Welder Machine Introduction This laser welder uses galvanometer scanning method, features high welding speed, high precision and good light beam mode, and is suitable for precision laser spot welding of various parts.
During single spot welding, the working efficiency is 4-10 times higher than common laser spot welding because the idle stroke positioning time is significantly reduced.
The scanning laser welder consists of YAG solid laser, laser power supply, optical scanning system, 3D adjustable work bench, industrial PC system, cooling system, laser indication system and operating cabinet.
This welder provides dedicated laser welding software based on Windows platform.
The welding spots or graphs can be imported and edited in the dedicated software, or edited in other software such as AutoCAD and CorelDraw and then processed in the dedicated software.
This welder features stable quality, convenient operation and easy maintenance.
Application This welder is mainly used in highly efficient laser spot welding or seal welding of mobile phone shielding case, mobile phone metal shell, capacitor metal shell, metal shielding grid in computer, shaver blade, electronic connector and other electronic products.
Techinical Parameters - - - -
Model | LX-D4 | Laser type | Nd: YAG | Laser wavelength | 1064nm | Maximum laser power | 100W/200W | Pulse width | 20ms | Pulse frequency | 50Hz | Spot welding speed | 15 spots/s | Size of light spot | 0.2-3.0mm | Adjusting range of light spot | 0.1-0.3mm | Maximum positioning speed | 7000mm/s | Resolution | 0.001mm | Repeating precision | 0.002mm | Cooling | Water cooling | Master unit dimensions | 1600*800*1500mm | - - - -
