Hxgn66 Medium Voltage Electrical Switchgear - China

Hxgn66 medium voltage electrical switchgear

reliable outdoor prefabricated substation

the main features

hxgn66 medium voltage electrical switchgear is a metal closed box structure, the cabinet body skeleton is welded by angle steel, using mechanical interlocking device and five-prevention program lock, simple and effective to meet the five-prevention requirements

the shell framework is designed with sectional assembly structure and module, it can combine at will according to different plan ark kind, convenient and quick, can rely on a wall to install, cover an area of an area small.

the height of cable terminal shall not be less than 700mm.

all parts in the cabinet shall be treated with reasonable surface treatment to meet the requirements of mechanism performance and service life.

the insulation parts used are large climbing cabinets with flame retardant performance.

the cabinet is equipped with a vacuum load switch, which is composed of an isolating knife and a vacuum arc extinguishing chamber.

hxgn66 medium voltage electrical switchgear about introduction

hxgn-12 unit type ac metal ring metwork switch equipment suitable for ac50hz, 12kv power system, as a power of acceptance and disreibution.

it is widely used in industrial and mining enterprises, high-rise buildings and other distribution systems.

environmental conditions for product use

ambient air temperature: upper limit +40℃ lower limit -10℃

humidity: daily average relative humidity does not exceed 95%; the monthly average relative humidity does not exceed 90%

earthquake: earthquake intensity does not exceed 8 degrees

in places without fire and explosion hazard, serious pollution, chemical corrosion and violent vibration

product advantage of safe outdoor prefabricated substation

small size, convenient maintenance, can effectively save the site

it has the advantages of compact structure and excellent performance.

it can not only be operated manually, but also operated electrically.

small opening and closing operating torque, light and simple operation.

more information can view here.
