Hydrogen Thyratrons Gl101 - China
price: contact company for price
Anode Parameter Peak forward anode voltage： 20kV
Peak anode current： 500A
Average anode current： 0.5 A
Rate of rise of anode current： 2000 A/μ s
Anode heating factor： 10×109VApps
Maximum pulse power： 5MW
Grid 2 drive Unloaded grid 2 drive pulse voltage： 200V～500V
Grid 2 pulse duration： 2μs
Rate of rise of grid 2 pulse： 2kV/μs
Peak inverse grid 2 voltage： 200V max
Forward impedance of grid 2 circuit： 50Ω～200Ω
Heater
Cathode heater voltage： 6.3V±5%V ac
Cathode heater current： 5A～7A
Reservoir heater voltage： 6.3V±5%V ac
Reservoir heater current： 1.0A～1.5A
Minimum heater time： 5min
Mechanical
DC grid 1 unloaded priming voltage ： 75V～150 V
DC grid 1 priming current： 75mA～150mA
Heater Mounting position： Any
Net weight： 360g approx
Dimension and tube connections： See outline
E2V： HY-11
Cooling way： Forced-air and natural (see notes )
Company Contact:
- Phone: +86-0512-36872107
- Address: ST28 Xihu Road, Kunshan, Jiangsu Province,China, Kunshan , Jiangsu , China
- Email:
- Website: https://www.glvac.com
Published date: August 8, 2017 - Modified date: August 23, 2017
- Business Description: GLVAC engages in R&D, manufacturing and selling the products of HV Relays, Vacuum Capacitors, Vacuum Interrupters, DC and AC Contactors, Circuit Breakers, Hydrogen Thyratrons, Magnetrons, Spark Gaps and other vacuum electrical apparatuses
