Japanese Brushed And Coreless Mini Dc 24v Maxon Motor Replacement For Healthcare Industry - China

Series: DR3068G

Japanese brushed and coreless mini DC motor 24V Maxon motor replacement for healthcare industry Warranty: 3months-1year


Place of Origin: Shanghai, China

Brand Name: SMJ

Usage: BOAT, Electric Bicycle, SMART HOME, Automation & Actuators

Type: Brush Motor

Torque: 28.1mNm

Construction: Permanent Magnet

Commutation: Brush

Protect Feature: Totally Enclosed

Speed(RPM): 7570rpm

Continuous Current(A): 0.93-1.46A

Efficiency: IE 1

Application: Automatic industry, Robots, AGVS, Tattoo gun

Torque max: 28.1mNm

brush type: graphite brushes

stall torque: 126.81mNm

diameter: 23mm

length: 46.9mm

certification: CE DC brushed motor (coreless) application:

1 - The healthcare industry: They can be used to power dialysis pumps, CPAP machines, surgery tools, and ambulatory infusion pumps.

2 - Robotics: Engineers install them in positioning systems and small wheel systems in robot projects.

3 - Automation & Actuators: These motors can be used in precise automation systems and high accuracy actuators.

4 - Laboratories: Engineers can use it to drive small but effective equipment such as pumps, stirrers, and centrifuges.

5 - Office equipment: Thanks to their small size, effective motors can be installed in printers, card readers, and other office

equipment, without the need to make the products bigger.

6 - Audio/visual equipment: Pan and tilt drives for cameras & audio turntables can be fitted with effective motors that work quietly.
