Jt6314a Programmable Dc Electronic Load 300w 15a 500v Test Led Driver And Ripple Wave - China

300W/15A/500V electronic load; 10uS full range current rising time; 500KHz synchronized sampling; taking great advantage in testing switching power supply, LED power supply, ATE, fuse, etc.

FEATURES: Modes & protection CC, CV, CP, CR, DYNA, List, Sweep, OCP modes.

LED mode, real simulating LED loading.

Over current, over voltage, over power, over temperature, polarity reversed protection.

Automatic test alone Press one button to complete load effect, ripple, dynamic, OCP and Short circuit test.

Show complete test report and support step test.

Multi load synchronous control

Support up to 16 loads Sync.

loading & dynamic test, fit for testing multi-output power supply.

Support up to 16 loads parallel mode for high power.

High rising speed (The full range current rising time is 10us)

High speed & accuracy

With 0.03% accuracy and 500kHz frequency, the current slew rate can be programmed.

500kHz sync.

sampling frequency with 15Hz data update rate, 0.03% accuracy, 10uA &100uV resolution.

Real-time measurement of Vpp/Vp+/Vp-/Ipp/Ip+/Ip-

Dynamic test and control

Up to 50kHz dynamic loading frequency & real-time measurement of peak voltage (Vp+/Vp-).

Support sync.

control and sync.

dynamic loading of multi loads.

Support frequency sweep up to 50kHz.

List function

8 List files, each file with 200 steps and 2us resolution.

Support up to 50kHz complex waveform editing.

Each step current slew rate can be programmed.

Automatic OCP Testing & Pmax Measurement

Automatically test OCP.

Capture automatically Pmax & the voltage and current when working at the Pmax point.

Trigger and timing measurement

Support voltage/current waveform trigger and timing measurement.

Support external trigger for the power supply startup time / hold time measurement.

Support waveform capture and test for OVP protection point and protection time.

Application of program controlling SCPI Protocol, isolated RS232 serial port.

5V/200mA power output, fit for the interconnection of equipments with different interfaces.

TRIG_IN, RI, DFI, TRIG_OUT four high-speed isolated I/O, supporting multi loads sync.

control.

Precision high speed digitizing measurement/ data capture(500kHz / 16 bits / 4096 points).
