Low Profile Rj45 Modular Jack 10 100 1000base T Single Port L829 1j1t 43 - China

price: check with company for price

Low Profile Rj45 Modular Jack 10 100 1000base T Single Port L829 1j1t 43

Products Photos Catalog Profile Rj45 Modular Photos Catalog

L829-1J1t-43 10/100/1000Base-T Single Port Low Profile Rj45 Modular Jack Electrical Characteristics @25 Turns Ratio: TP1 1CT: 1CT 20% TP2 1CT: 1CT 20% TP3 1CT: 1CT 20% TP4 1CT: 1CT 20% OCL @ 100KHz/100mVMS (0-70 Deg.

C) 8mA DC BIAS 350uH MIN INS.

LOSS 0.1MHz TO 1MHz -1.1 dB MAX 1MHz TO 65MHz -0.5 dB MAX 65MHz TO 1MHz -0.8 dB MAX 100MHz TO 1MHz -1.2 dB MAX RET.

LOSS (MIN) @ 100OHMS +/-15% 0.5MHz-40MHz -18 dB 40MHz-100MHz -12+20LOG(f/80MHz) dB CM TO CM REJ 100KHz-100MHz -30 dB MIN CM TO DM REJ 100KHz-100MHz -35 dB MIN HIPOT (Isolaton Voltage) 1500 Vrms 100% OF PRODUCTION TESTED TO COMPLY WITH IEEE 802.3 ISOLATION REQUIREMENTS.

LED 1 VF (FORWARD VOLTAGE) IF=20mA YELLOW 2.1V TYP VD (DOMINANT WAVELENGTH) IF=20mA YELLOW 590nmTYP LED2 VF (FORWARD VOLTAGE) IF=20mA YELLOW GREEN2.2V TYP AMBER 2.1V TYP VD (DOMINANT WAVELENGTH) IF=20mA YELLOW GREEN 570nm TYP AMBER 607nm TYP MIXED YELLOW DOES NOT HAVE SPECIFIC WAVELENGTH.

L829-1J1t-43 10/100/1000Base-T Single Port Low Profile Rj45 Modular Jack L829-1J1t-43 10/100/1000Base-T Single Port Low Profile Rj45 Modular Jack HOW TO ORDER 1 - Please send me your datasheet or part number you need.

2 - We will offer the replacement quotation for your reference 3 - The free samples are available for your approval.

4 - After sample testing, we will step into the mass order.

5 - The Proforma Invoice will send for your confirmation 6 - After the goods finished, we send the goods to you and tell you the tracking number.

7 - We will track your goods until you receive the goods.

Remarks: 1 - Sample orders are avaliable.

2 - Price is negotiable for orders of large quantity.

3 - Customized orders (OEM/ODM orders) are avaliable.

4 - Contact us for available flavors list.

International Certifications: 1 - ISO9001: 2008 2 - UL 3 - Reach 4 - RoHs Our service: 1 - 100% tested before shipping 2 - Have alternative for Halo, Pluse, Wurth, We-online, Chilisin, CoilcraftSame quality but better price 3 - Free sample available 4 - Provide new design for customer


Company Contact:


  • Phone: 86-0755-32932627

  • Address: C711 HUAQIAOXINCUN, MINZHI TOWN , LONGHUA NEW DISTRICT , 518131 , SHENZHEN ,CHINA, Shenzhen , guangdong , China

  • Email: Email


Published date: January 8, 2018

  • Business Description: Established in 1998, we have around 500 staff at present.

    With the abundant productive capacity , we are able to delivery the goods within the short time.

    Moreover, we can provide the professional complete solution for PoE appliication.
