Modbus Internet M2m Gateway Non Condensing 8 Channels Digital Output - China

machine to machine internet gateway, m2m gateway device System Feature # Cortex M3 32-bit ARM # Reliable performance with built-in double watchdog, 247 operation # Dual digital filters for anti-noise # Support automatic network reconnection and data re-send # Synchronize clock with multiple way, Sms, NTP, CwtIO Server # Can set multiple timers(second, minute, day, week, month) to execute actions, e.g. output, upload data, change setting # Support Interlock programming, Event trigger # Provide configure software, visual programming, over 100 parameters can be set # Optional inside lithium battery for power lost alarm and keep 8-20 hours working DI feature # Monitor dry contact(NO or NC) DO(T) feature # Relay drivable output(drive voltage=power supply voltage, Drive current500mA) # on/off/pulse DO by remote control or local event # Remember status when power lost DO(K) feature # Relay output(NO, contact load: 2A / 125VAC, 220VDC) # Remote or local event activate DO on/off/pulse # Remain down status when power lost AI feature # 4-20mA (option: 0-5V) in, Sampling frequency: 33Hz, 10-bit precision) # Convert 4-20mA(0-5V) to physical value # Can set parameters for value processing, alarm, data transmission # Signal lost alarm SMS feature # Can add 10 administrator numbers for alarm and remote control # Sms alarm when any IO channel triggered or out of preset normal range # All alarm and recover sms text can be edited # Query any IO channels status or value via sms command # On/off/pulse output by sending sms # Sms report any IO channels status or value on schedule # Remote update parameters by sms # Sms remind for sim card overdue # Power lost and recover alarm by sending sms Wireless network communication # With 2g, 3g, 4g, Wi-Fi version # TCP/IP connect at most 4 servers(support Static IP address or domain) # Events(e.g. alarm, timer) trigger upload data # Communication protocol: Modbus TCP, http post, Cwt_IO(two-way communication) # Transfer RS485 or RS232 Data to wireless network Modbus feature # Can work as a modbus master to poll salve over RS485 # As a RS485 I O module to be polled by modbus master # As modbus to gprs/3g gateway

Company Contact:

• Posted By: CWT(HK) Co., Limited

• Phone: 86-755-26719943

• Address: 7/F, Block A, Building F1, TCL International E City, No.1001 Zhongshanyuan Road, Nanshan District, S, Shenzhen , Guangdong , China

• Email:

• Website: https://www.iotgatewaydevice.com

• Business Description: Whatever term you use for Telemetry, whether it's remote monitoring, M2M, Machine2Machine, Machine2Man or even Man2Machine then CWT wire free telemetry products will serve you well.

  Our Telemetry Solutions have been designed with the user in mind, so they are cost-efficient, easy to configure and in
