Monopole Transmission Tower - China

A monopole transmission tower is a type of electricity transmission tower consisting of a single tall pole made of steel or concrete designed to support overhead power lines.

These towers are increasingly popular due to their minimal footprint and lower visual impact compared to traditional lattice towers.

Key Features of Monopole Transmission Towers

Structure: Monopole towers are characterized by their single, tubular structure.

They are often made of galvanized steel or reinforced concrete, providing strength and durability.

The design can vary in height but typically ranges from 30 to 200 feet tall, depending on the voltage of the power lines they carry and the geographical requirements.

Aesthetics: Monopoles have a sleek, unobtrusive design that is often preferred for urban or suburban areas where larger lattice towers might be considered unsightly.

Their simplicity allows them to blend more easily into the landscape.

Footprint: These towers require less ground space compared to traditional multi-legged lattice towers, making them ideal for locations with limited space or environmental sensitivity.

This small footprint also simplifies the site preparation and foundation requirements.

Installation: Monopole towers are generally easier and quicker to install than lattice towers.

They are usually prefabricated and shipped to the site in sections, which are then stacked and bolted together.

This reduces construction time and potentially decreases installation costs.

Capacity and Use: Despite their slender appearance, monopoles are capable of supporting large loads.

They are typically used for medium-voltage lines but can also be engineered to carry high-voltage lines over long distances.

The poles can be equipped with arms or crossbars to support multiple circuits if needed.

Durability: The use of galvanized steel or reinforced concrete ensures a long service life for monopole towers, with minimal maintenance required.

The materials are chosen to withstand harsh weather conditions and environmental challenges.

Advantages: Reduced Visual Impact: Monopoles are favored in scenic areas or where community impact needs to be minimized.

Versatility: They can be used in a variety of settings, including urban, suburban, and rural areas.

Environmental Compatibility: The smaller footprint and reduced number of components make these towers less disruptive to the environment.

Applications: Highway and Railway Crossings: Their minimal space requirement makes monopoles suitable for narrow corridors like those along highways and railways.

Urban Energy Distribution: Ideal for densely populated areas where space is at a premium.

Renewable Energy Projects: Often used in wind farms and solar power plants to carry generated power to the grid.

Monopole transmission towers are an efficient, modern solution for transmitting electricity across various terrains and through populated areas.

Their design minimizes visual impact while maximizing functionality, making them a preferred choice for new transmission projects where space and aesthetics are significant considerations.

Product monopole transmission tower

Shape Polygonal or Conical

Material Normally Q345B/A572, Minimum Yield Strength ≥ 345 N/mm² Q235B/A36, Minimum Yield Strength ≥ 235 N/mm².

OR Q420 Q460 ASTM A572 GR65, GR50, SS400

Electric Voltage 4kv, 6kv, 10kV, 11kv, 33kv, 32kv, 35kv, 65kv, 66kv, 110kv, 132kv, 135kv, 220kv, 230kv, 330kv, 380kv etc.

Surface treatment Hot dip galvanized Following ASTM A 123, BS729 or as client required.

connection Slip joint, flanged connected

Standard ISO 9001: 2008

Welding Standard AWS (American Welding Society ) D 1.1

Production Process Raw material test → Cutting →bending →Welding (longitudinal )→Dimension verify →Flange welding →Hole drilling →sample assemble → surface clean→ Galvanization or powder coating, painting →Recalibration →Packages

Packages Packing with plastic paper, bundle, wooden box or steel box or according to client’s request.

Deshi Tower specializes in the design, manufacture, and construction support of transmission towers, communication towers, steel structures, and observation towers.

Transmission tower design adheres to ASCE/SEI standards.

Telecommunication tower design follows ANSI/TIA-222 standards.

We are not just manufacturers and suppliers, but also your technical support and partners.
