Nov Brandt King Cobra Composite Shaker Screen For Drilling Waste Management Equipment - China

NOV Brandt King Cobra Composite Shaker Screen for drilling waste management equipment 1: Description NOV Brandt King Cobra Composite Shaker Screen for drilling waste management equipment improved performance and reliability over traditional metal-backed screens.

The design features a soft gasket that allows the screen to be removed and reinstalled while maintaining a reliable sealing mechanism.

Improvements increase screen life and provide significant operator savings.

2: Specifications - - - - Product name | NOV Brandt Shaker Screens used in Composite King Cobra Shale Shaker | Wire mesh material | SS304 SS316 or customized as customers demands | Size | 1251 x 635 mm | Weight | 13 kgs | Screen layers | 2 or 3 layers | Mesh count | 20-325mesh | Quality standard | Compliant with OAPI RP13C Standard | - - - - 3: Application Shale shaker screen widely used in petroleum drilling machine, solids control equipment, desander, desilter and so on.

Especially, it is the important fitting of drilling slurry purified equipment.

For acid, alkali conditions screening and filtering.

Used as Mud network for the oil industry, chemical fiber industry for filter screen, electroplate industry to make pickling network, etc.

4: Technical details The screen's material is epoxy glue.

We use excellent level wire cloth(304, 316), the material epoxy glue has environmental suitability.

The curing temperature is above 220 degrees.

The softening temperature is 140 degrees.

The sealing rubber strip is NBR, so our screens could meet the terrible acid-base environment.

We can provide three-layer even four-layer all types of screen cloth.

About API standard, all our screens are been tested in the drilling sites and laboratory.

According to our clients feedbacks, our screens are completely conformed to API RP 13C.

The material of steel frame is Q235 - The composite material is modified polypropylene.

5: Pictures
