Ns75 90 Overhead Csa - China
price: contact company for price
Voltage
600V Construction
Sino-cables type NS75/90 has stranded aluminum alloy 1350-H19 hard drawn compact round conductors and a stranded round compact strand ASCR neutral.
NS75/NS90 cables have abrasion, heat and moisture resistant cross linked polyethylene XLP insulation.
NS75/NS90 cables may have a heat and moisture resistant polyvinyl chloride PVC jacket, which has a temperature range of -40ºC to +90ºC Standard
CSA C22 - C No.
129, or other standards required by customers.
Features
Low temperature.
Sunlight resistant.
Max permissible continuous operating temperature of conductor shall not exceed 90°C.
Applications
Sino cables type NS75/NS90 are intended for use either as a service drop cable between a power pole and the service entrance, or as a secondary distribution cable between poles.
Package
coil, steel/wooden reel, wooden reel or steel reel.
Company Contact:
- Posted By: Jiangsu Sanqi Cable & Wire Co., Ltd,
- Phone: 0513-68971818
- Address: the west end of Yongtong Avenue, Rudong , Jiangsu , China
- Email:
Published date: June 21, 2017
- Business Description: Sino-Cable manufacture cables with AA 8000 series aluminum alloy cable, power cable, rubber cable, solar cable, xhhw-2, use-2, ser/seu, MC, MHF, UD Wire Cable.
