Optianal 3g 4g Cwt M2m Gateway Solution Wireless Communications System - China

CWT m2m wireless communications system, m2m gateway solution System Feature # Cortex M3 32-bit ARM # Reliable performance with built-in double watchdog, 247 operation # Support signal fileter # Support automatic network reconnection and data re-send # Synchronize clock with multiple way, Sms, NTP, CwtIO Server # Configurable action schedule(second, minute, day, week, month) # Can automatically execute tasks according to preset Events # Easy used GUI configure software for setting up to 100 parameters # Optional inside lithium battery for power lost alarm and keep 8-20 hours working DI feature # Trigger dry contact(NO or NC) DO(T) feature # Transistor output(drive voltage=power supply voltage, Drive current500mA) # Remote or local event activate DO on/off/pulse # Remember status when power lost DO(K) feature # Relay NO output(load: 2A / 125VAC, 220VDC) # DO can be activated by remote or local schedule # Remember status when power lost AI feature # Accept 4-20mA (option: 0-5V), Sampling frequency: 33Hz, 10-bit precision) # Transduce 4-20mA(0-5V) to actual value # Support offset and gain, alarm parameters, upload data setting # Sensor disconnect alarm SMS feature # Preset 10 phone numbers (support distribute authority to receive sms) # Send sms alarm when input is triggered or reach alarm level # All alarm and recover sms text can be edited # Query any IO channels status or value via sms command # On/off/pulse output by sending sms # Can set interval to report IO channel's status or value by sms # Remote setting via sms commands # Can query SIM card balance, sms forward # Power lost and recover alarm by sending sms # Wireless network communication # With 2g, 3g, 4g, Wi-Fi version # Support TCP/IP two-way communication with Max.

4 servers(IP or domain) # Events(e.g. alarm, timer) trigger upload data # Communication protocol: Modbus TCP, http post, Cwt_IO(two-way communication) # Transfer RS485 or RS232 Data to wireless network Modbus feature # Can work as a modbus master to poll salve over RS485 # Can be a I O module to be read/write by modbus master # As modbus to gprs/3g gateway TI feature # Option temperature probe or temperature&humidity probe, support alarm, interlock, data communication # Fahrenheit or centigrade units for temperature # Support probe disconnect alarm
