Panasonic Low Profile Signal Relay Ds2e S Dc24v - India

price: check with company for price

Panasonic Low Profile Signal Relay Ds2e S Dc24v

Products Photos Catalog Panasonic Profile Photos Catalog

Panasonic 2A 24VDC DPDT SEALED PCB Low Profile Signal Relay - DS2E-S-DC24V

FEATURES: -

• High sensitivity: 200 mW pick-up power 100 mW pick-up power types available

• Latching types available

• High switching capacity: 60 W, 125 V A

• High breakdown voltage: 1, 500 V FCC surge between open contacts 1, 000 V AC between open contacts

• DIP-1C type can be used with 14 pin IC socket 2C type can be used with 16 pin IC socket, 4C type can be used with 2 sets of 14 pin IC sockets

• Gold-cap silver palladium types available for 2 Form C type

• Bifurcated contacts are standard

APPLICATIONS: -

• Telecommunication equipment

• Office equipment

• Computer peripherals

• Security equipment

• Measuring instrumentation

DESCRIPTION: -

Manufacturer: Panasonic

Product Category: Low Signal Relays - PCB

RoHS: RoHS Compliant By Exemption Details

Brand: Panasonic Industrial Devices

Product: Low Profile Relays

Type: Miniature

Coil Voltage: 24 V

Contact Form: DPDT (2 Form C)

Contact Current Rating: 3 A

Maximum Switching Current: 3 A

Coil Current: 8.3 mA

Coil Type: Non-Latching

Power Consumption: 200 mW

Contact Rating: 2 A at 30 VDC

Contact Termination: Solder Pin

Mounting Style: Through Hole

Packaging: Tube

Factory Pack Quantity: 50

POPULAR PRODUCTS: -POPULAR PRODUCTS: -

5 VDC SPST (1 Form A) Low Signal Relays - PCB, 12 VDC SPDT (1 Form C) 16.7 mA Low Signal Relays - PCB, Latching DPDT (2 Form C) Low Signal Relays - PCB, Latching 3 VDC Gull Wing Lead 11.7 mA Low Signal Relays - PCB, DPDT (2 Form C) Communications Relays Low Signal Relays - PCB, 24 VDC 8 A Low Signal Relays - PCB etc


Company Contact:


  • Phone: 9810618342

  • Address: SCF#- 17, 2nd Floor, Opp. Satyam Guest House, Sec. 16, Faridabad -121002, Haryana, faridabad , haryana , India

  • Email: Email

Published date: November 8, 2016 - Modified date: November 8, 2016
