Red Single Core Fireproof European Standard Solar Pv Cable - China

Red single core fireproof European Standard solar pv cable

Widely used in indoor and outdoor solar installations, electrical installation, indoor and outdoor, explosion-prone areas, factories, industrial and agricultural industries.

Low smoke without halogen, good cold, ultraviolet, ozone - resistant and weather - resistant.

Flame retardant, cutting resistance and penetration resistance.

Cable protection level Ⅱ level.

With 150 ℃ photovoltaic cable radiation as insulation materials, halogen free flame retardant is halogen-free, non-toxic modified polyethylene thin hengjing resin as the main raw material, add halogen-free, non-toxic, flame retardant, heat stabilizer, eliminate smoke agent, preservative, such as fertilizer, does not contain halogen, heavy metals, phosphorus.

It conforms to ROHS, and the insulation resistance is small after immersion.

1 - The dc resistance: the finished cable at 20 ℃ conductive wire core dc resistance is not greater than 5.09 Ω/km 2 - The insulation resistance: the finished insulation resistance of cable at 20 ℃ should not less than 1014 Ω.

Cm, finished cable insulation resistance at 90 ℃ is not less than 1011 Ω.

Cm

Ambient temperature: - 40 ℃ ~ + 90 ℃

The highest temperature of conductor: 120 ℃ (allow 5 s in short circuit temperature 200 ℃)

Limited voltage: AC0.6/1kv dc1.8kv 3 - The sheath surface resistance: resistance of the finished cable sheath surface should be not less than 109 Ω.

SHANGHAI HONGSHENG WIRE AND CABLE CO., LTD., located in no.

7, no.

4769, Jinqian High Way, Fengxian district, Shanghai, China, is a National High-tech Enterprise and the president enterprise of Shanghai wire and cable association.

Our company is a collection of professional research and development, design, production, sales of special wire and cable.

Company in line with to the science and technology as the first productive force, long-term commitment to three areas of research and management--building cable, new energy cable and Industrial equipment automation cable.

After years of development, in all areas of wires and cables have been widely recognized in the industry and good market reputation.
