Single Phase Audio Amplifier Transformer 749196111 Ce Rohs Approved - China

Power Transformer 749196111 Switch Mode Transformer For Audio Amplifier SMPS Flyback Transformer Electrical Properties: - - - - Properties | Test conditions | | Value | Unit | Tol.

| Inductance base | 10 kHz/ 100 mV | Lbase | 27.4 | H | 20% | Turns ratio | N1: N2: N3: N4: N5: N6 | n | 1: 1: 1: 1: 1: 1 | | | Rated Current base | T = 40K | IR base | 0.55 | A | typ.

| Saturation Current base | |L/L| < 10% | Isat base | 0.22 | A | typ.

| DC Resistance base | | RDC base | 344 | m | max.

| Voltage-Second base | @ 20C | Udt base | 32.9 | Vs | max.

| Leakage Inductance base | 100 kHz/ 100 mV | Ls base | 0.21 | H | typ.

| Insulation test voltage | 3 mA/1 s | UT | 500 | V (AC) | | - - - - # 1)Inductance of a single winding # 2) Rated Current of a single winding # 3) Saturation Current of a single winding when all windings are driven.

If not all windings are current driven the Saturation current per winding is6x Isatbase / number of driven windings # 4) DC Resistance of a single winding It is recommended that the temperature of the part doesnot exceed +125C under worst case conditions.

# Storage Temperature: -40C to +85C # Operating Temperature: -40C to +125C # Test conditions of Electrical Properties: 20C, 33% RH if not specified differently Power Transformer 749196111 Switch Mode Transformer For Audio Amplifier D Electrical Properties: Product Picture: Power Transformer 749196111 Switch Mode Transformer For Audio Amplifier HOW TO ORDER 1 - Please send me your datasheet or part number you need.

2 - We will offer the replacement quotation for your reference 3 - The free samples are available for your approval.

4 - After sample testing, we will step into the mass order.

5 - The Proforma Invoice will send for your confirmation 6 - After the goods finished, we send the goods to you and tell you the tracking number.

7 - We will track your goods until you receive the goods.

Remarks: 1 - Sample orders are avaliable.

2 - Price is negotiable for orders of large quantity.

3 - Customized orders (OEM/ODM orders) are avaliable.

4 - Contact us for available flavors list.

International Certifications: 1 - ISO9001: 2008 2 - UL 3 - Reach 4 - RoHs Our service: 1 - 100% tested before shipping 2 - Have alternative for Halo, Pluse, Wurth, We-online, Chilisin, CoilcraftSame quality but better price 3 - Free sample available 4 - Provide new design for customer
