Single Port Rj45 Magnetic Jack Hr911105a 10 100 1000baase With Module Led - China

HR911105A 10/100/1000Baase Single Port Magnetics RJ45 Jack with Module and LED Product Details: # Designed for Network Interface Card Application.

# Meets or Exceeds IEEE802.3 standards including 350uH Min OCL with 8mADC.

# High performance for EMI suppression, Crosstalk, Return Loss and Consistent Electrical.

# Minimum 1500Vrms isolation per IEEE802.3 requirement.

# Minimize PCB space and Simplify PCB Layout.

# Less magnetic components to place on PCB, Higher reliability and yields.

Electrical Specification @25 # Isolation: 1500Vrms (UTP Side to Chip Side) # OCL: 350uH Minimum @100KHz 100mV with 8mADC.

# Insertion Loss: -1.0dB Maximum @300KHz-100MHz # Return Loss: -20dB Maximum @1MHz-10MHz -16dB Maximum @10MHz-30MHz -12dB Maximum @30MHz-60MHz -10dB Maximum @60MHz-80MHz # Common Mode Rejection: -30dB Maximum @1MHz-50MHz -20dB Maximum @50MHz-150MHz # Crosstalk: -40dB Maximum @1MHz-30MHz -35dB Maximum @30MHz-60MHz -30dB Maximum @60MHz-100MHz HR911105A 10/100/1000Baase Single Port Magnetics RJ45 Jack with Module and LED HR911105A 10/100/1000Baase Single Port Magnetics RJ45 Jack with Module and LED HOW TO ORDER 1 - Please send me your datasheet or part number you need.

2 - We will offer the replacement quotation for your reference 3 - The free samples are available for your approval.

4 - After sample testing, we will step into the mass order.

5 - The Proforma Invoice will send for your confirmation 6 - After the goods finished, we send the goods to you and tell you the tracking number.

7 - We will track your goods until you receive the goods.

Remarks: 1 - Sample orders are avaliable.

2 - Price is negotiable for orders of large quantity.

3 - Customized orders (OEM/ODM orders) are avaliable.

4 - Contact us for available flavors list.

International Certifications: 1 - ISO9001: 2008 2 - UL 3 - Reach 4 - RoHs Our service: 1 - 100% tested before shipping 2 - Have alternative for Halo, Pluse, Wurth, We-online, Chilisin, CoilcraftSame quality but better price 3 - Free sample available 4 - Provide new design for customer
